Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Mm: |
200*200 |
| Type: |
Rigid |
| Number Of Layers: |
Double Layers |
| Dielectric: |
FR-1 |
Product Description
ShenZhen JINGHUAXING Electronics Co., Ltd. is a professional PCB manufacturer established in September, 2000. Now we are employs more than 280 people.
We possessed the capability of making 2-30 layers PCB with HDI, blind/buried hole, high frequency, metal base(Alu base, cu base, iron base), high Tg, thick copper power supply and so on.
The output of multilayer PCB reaches over 10, 000 Square meters Square meters including thousands of samples and fast board.
We obtained ISO9001: 2000, UL and RoHS certificate.
Our company and products are developing steadily in domestic market and sharing good reputating in overseas market by excellent quality, competitive price, punctual delivery, best service and high efficiency as well as continuous upgrading technology.
Max. Board Size: 23inch * 35inch
Board Thickness: 0.4-6.0mm
Min. Line Width: 0.10mm
Min. Space: 0.10mm
Min. Hole Size: 0.15mm
PTH Wall Thickness: >0.025mm
PTH Hole Dia. Tolerance ± 0.05mm
V-cut: 30° /45° /60°
Min. BGA PAD: 14mil
E-test Voltage: 50-250V
Soldexability Test: 260d 20second
Shenzhen Jinghuaxin Electronics Co., Ltd. is a professional PCB manufacturer established in September, 2000. Now we are employs more than 280 people.
We possessed the capability of making 2-30 layers PCB with HDI, blind/buried hole, high frequency, metal base(alu base, cu base, iron base), high tg, thick copper power supply and so on.
The output of multilayer PCB reaches over 10, 000 square meters square meters including thousands of samples and fast board. We obtained ISO9001: 2000, UL and RoHS certificate.
Our company and products are developing steadily in domestic market and sharing good reputating in overseas market by excellent quality, competitive price, punctual delivery, best service and high efficiency as well as continuous upgrading technology.
