Product Specifications
| Prod Model: |
Positive displacement flow meter |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Volume Type Flow Meter |
| Measuring Principle: |
Mechanics |
| Measuring Media: |
Liquid |
| Main Application: |
Corrosive Liquid/Gas |
| Sensor: |
Plug-in |
| Accuracy: |
+-0.2% |
| Measurement Object: |
Fuel,Gasoline, Diesel,Water...etc |
| Application: |
Petroleum |
Product Description
Electronic type stainless steel Positive Displacement Flow Meter with a communication box
Excellent stepless adjusting mechanism allows a micro adjustment of the meter;
High accuracy and repeatability over the widest range of flow; Superior accuracy at constant flow;
Low maintenance, no metal-to-metal contact in measuring chamber, Long life service;
Low pressure loss, a true gravity flow meter;
Accuracy regardless of pressure fluctuations, temperature variation, viscosity;
Choice of aluminum, cast iron, brass and stainless steel materials of construction.
Quick Details
Place of Origin: Zhejiang, China (Mainland)
Brand Name: High Accuracy Positive Displacement Flow meter
Size: 1.5 inch, 2 inch, 3 inch, 4 inch, 6 inch
Accuracy: +-0.2%
Flow Range: About 250L/min, 500L/min, 1000L/min, 1300L/min, 3000L/min.
Max. Pressure: 10 Bar/150 PSI
Repeatability: Less than 0.05%
Standard Measurement: Liter/US Gallon/IMP Gallon
Maintenance: No Metal-To-Metal Contact In Measuring Chamber
Accuracy Regardless Of: Pressure Fluctuations, Temperature Variation, Viscosity
Meter Material: Aluminum, Cast Iron, Stainless steel
We are professional manufacturer and exporter of petroleum equipment in China and founded in 1992, have established cooperative relationships with customers in more than 100 countries and regions.
Our products including:
-Fuel dispenser(flow rate 50l/min), lpg dispenser, super high flow dispenser (flow rate from 90l/min to 800l/min)
-Relevant parts for fuel/lpg dispenser such as vane/gear pump, tokheim pump and flow meter, motor, electronic controller. Nozzle, swivel, breakaway, flexible pipe, filter, solenoid valve, pulser, mainboard, power board, display board, lpg pump, lpg flow meter, lpg nozzle etcl.
-Industrial pump and flow meter such as positive displacement flow meter, positive displacement rotary vane flow meter, rotary vane pump etc.
-Other oil equipment such as liquid level instrument system, electric transfer pump, stainless steel measuring apparatus, sampling instrument, measuring scale for oil tank...Etc.
-Equipment for adblue like stainless steel nozzle for adblue etc.
We, are looking forward to even greater cooperation with overseas customers based on mutual benefits. Please feel free to contact us for more details.
