SPECIFICATIONS
Frequency and Level
Frequency Range: 46 -----------870MHz
Resolution Bandwidth: 280KHz +- 50 KHz
Channels: All user designate Channels
Level Range: 30dB UV ----115dB UV
Accuracy: +-1.5dBUV(under room temperature )
+-2.5dBUV(-10----+40 )
Input impedance: 75(BNC of F connector )
Wave detection: Peak value
Auto scan testing
Max Channel Scan: 125 Channels
Scan Range: All Channels within 5(46)---870MHz
Scan speed: 30 Channel Is /Min
Memory Groups: 14 Groups (00--13) Each group store Max 100 Channels.
Voltage
Voltage Range: 0-----100VAC
Accuracy: +- 1.5 V
Resolution: 0.1 V
C/N (the result is only for reference )
Level Range: 80dBUV-----105dBUV
Others
Dimension: 214mm*94mm*47mm
Weight: 1.4 kg
Working Temperature: -10 ------+40
Display LCD: TN LCD with back light
Power
DC Supply: DC 7.2V /1.5 Ah rechargeable battery
AC Supply: AC 220V /50Hz +- 10%
Battery working hours: Longer than 4.5 hours at continuous working mode
Recharging hours: 12------14 hours.
| Name |
Free Shipping Analog Signal Level Meter |
|
|
