DLDJ-BT01
Frequency Control of Motor Speed Training Set
1.Overview
This device is on the basis of the current frequency control of motor speed practice teaching equipment, offering a advanced frequency conversion speed control device, this training device provides advanced operating platform for frequency conversion technology training and examination. Converter choose widely used mitsubishi FR - A740-0.75 KW converter, RS485 communication interface. Training platform can complete "frequency control of motor speed technology" course related teaching practice. Especially provide the open practice teaching, and it can fully cultivate students' practical ability, lay a solid foundation for the jobs.
2.Technical feature
Input power: Three phase four wire (or three phase five line) ~ 380 v - 10% of the 50 hz
Working environment: Temperature relative humidity < 85%
Capacity: < 0.5 KVA
Physical size: 1600 mm * 700 mm * 1630 mm
Safety protection: Has the drain voltage, leakage current protection, safety conform to the state standards.
The training project
Relay contact control training
Three phase asynchronous motor inching control and locking control
Three phase asynchronous motor Y/ in joint start control
Three phase asynchronous motor interlocking positive &negative control
Three phase asynchronous motor delay positive &negative control
Frequency conversion control training
Converter function parameter establishment and operation
Converter alarm and protection function
Multiple speed selection frequency control of motor speed
External terminal inching control
External terminal remote control
Control motor running time operation
Control motor positive &negative motion control
Voltage/current monitor signal output and display
Instant power inverter parameter setting
Based on the frequency control of motor speed of RS485 communication
Based on the triangle wave frequency control of motor speed control
Three phase asynchronous motor frequency control of motor speed
Frequency constant pressure water supply analog control
3. Factory:
Our factory located in Pioneering park overseas Chinese Scholars Jinan city, Shandong Province .
We have very strong technical teams with more than 40 engineers and experienced workers. Our products have exported for more than 7 years.
4. We are in a good position to offer series of training set as follows:
1) Electrical technology Know-how Training Set
2) Innovative E-skills&Technology Training Series
3) MCU Technology Training Series
4) Machine Tools Electrical Control Training Series
5) Machine Tools Electrical Control Training Series(Model-type)
6) CNC Machine Tools Maintainance Training Series(Model-type)
7) Building Automatic Training Series
8) PC Training Series
9) Innovative industrial Automatic Control Technology Training Series
10) Pnematic Training Series
11) Hydraulic Training Series
12) Sensor Training Series
13) Motor Training Series
14) Mechatronic Training Series
15) MPS Training Series
16) FMS Training Series
17) Mechanical Training Series
18) Process control series
19) Automotive training series
20) New energy training series
5. Packaging And Delivery Details:
Packaging Detail:
1). Packaging for training kit: plastic package + carton + plywood pallets
2). Packaging for training equipment: plastic package + plywood pallet
Delivery Detail: 40 to 50 days after Received advanced payment.
6.After-Service And Training for Foreign User
1) For our exported equipments, the Warranty is one year, within one year, if there is any problem for spare parts(except damage by man-made) We can supply and replace free of charge. And if after one year, we also supply the service. The difference is user need to pay it.
2) We dispatch our professional and experienced engineer to install equipments and make training for the end users.
