Fs02 Bluetooth Android Mobile Barcode Scanner

Product Specifications

Prod Model:	FS02
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Data Collector
Certification:	RoHS
Currency Detector Type:	Portable Handheld Detector
Queue System Usage:	Semi-outdoor
Data Collector Signal Transmission:	Wireless
Data Collector Operating System:	Android
Currency Detector Principle:	Coms

Product Description

FS02 bluetooth Android mobile barcode scanner



Product Description
Product Introduction:
1: 2D Bluetooth Wearable Ring-style Barcode Scanner UL-FS02 is a powerful new generation mini barcode scanner with small size and charming appearance. It is designed for picking and sorting application, enable your operator to free hand and improve operational efficiency in your warehouse, distribution center and retail store. You never need setting an item down to check paper work order or picking up handheld scanner. Operator even no need to put heavy packageto the desktop for scan, it will save more time and physical strength. Compare with common wired handheld scanner, UL-FS02 can increase 15%-30% productivity!
2: UL-FS02 wearable ring scanner enable operator to move package ,
products and materials, helping to increase more efficiency, It is very comfortable to wear it in whole working day, with high performance laser scan engine, even poor printed barcode can be read. The rugged rubber shell makes daily use reliable even in the roughest environments.

3: UL-FS02 wireless function allowing unparalleled freedom for movement in scanning,
it can be avoid drop down and damage scanner when you wearing on the finger. Super Class2 Bluetooth technology and long range 2.4G antenna make you transfer data with 20M distance. You never need add more headcount to finish more work equip with UL-FS02 wearable ring-style scanner.
At the same time, we provide RS232 and USB version to connect PC and Electronic label shelf

4:UL-FS02 can connect with iOS and android smart phone easily.
Special design Bluetooth protocol, you can scan barcode into tablet PC and smart phone directly without install any software, double push trigger button, you can display and hide soft keyboard in iOS.


Main parameters

Specifications
Operating current	12mA(standby); 150mA(scanning;180mA (transmitting)
Standby time	Over 4 days
Operating time	6 Hours
RF module	Bluetooth V2.0+EDR, Class II
Bluetooth profile	HID; SPP master; SPP slave
Data storage	10MB(standard Batch, out of range batch), 50MB (U Disk)
Working range	10 meters
Dimensions	110H*43W*25D mm
Weight	89g
Radio link	2402~2480MHz FHSS/GFSK modulation, 79 channels at 1 MHZ intervals
Key & Trigger	1 / million presses
Display	LCD backlight
Color	White /Black
Battery	950 mAh Lithium-ion battery
Charge time	fully charge(>80%) in 3.5 Hours
Case material	ABS
Light source	650nm visible laser diode
Scan rate	100 time per sec.
interface	USB Keyboard, USB virtual COM
Decode capability	all major 1D 2D barcode symbologies including Gs1 DataBar variants
Keyboard layout	USA, Turkish F, Turkish Q, French, Italian, Spanish, Slovak, Denmark, Japanece
Indicator	Beeper, LED, LCD
Operating method	Handheld
Programming method	manual(reading special barcode)
Fimware	online via USB







Accessories services
Package:

1: Finger Mini Barcode Scanner
2: USB Cable
3: rubber belt
4: User Maual

Warranty:

1: bluetooth barcode reader is guaranteed for one year
2: battery warranty half a year
3: offer lifetime maintenance
