Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black |
| Brand Name: |
Sclass |
| Model Number: |
S1 |
| USB Port: |
Yes |
| HDMI: |
Yes |
| PVR: |
Yes |
| Original Receiver: |
Yes |
| 1080I: |
Yes |
Product Description
1. Main Chipset: ALI3601S
2. Mechanical: 2F CASE
3. RCA with CVBS, TV SCART, HDMI, RF, S/PDIF
4. 1080I supported
FTA HD DVB-s2 1080I
1. Main Chip Sets----Flash Memory: 16MB Serial Flash; DDR2 Memory: 512MB;
Demodulator IC: ALI3601S
2. DVB-S2 Tuner----Tuner Type: AV2011; Input Frequency Range: 950MHz-2150MHz;
Input Impedance: 75Ω; RF input Signal LEVEL: -80/-20dBm
3. DVB-S2 Channel Decoder----Demod standard: DVB-S2 Standard; MPEG Profile Level: MPEG2 SD, MPEG2 HD, H. 264/AVC SD, H. 264/AVC HD, MPEG4 AVC/H264;
Demodulation: QPSK, 8PSK, 16QAM, 64QAM; FFT SIZE: 2K, 8K
4. USB Decode----DVR supporting: Stereo/MONO/Left/Right;
Media Supporting: FAT12, FAT16, FAT32, NTFS (only support first partition);
USB2.0 High Speed HOST: DVR with USB HDD, Time shifting with USB HDD
5. Multimedia support format----movie: Mpg, AVI, MKV, DIVX (version 4, 5, 6);
Music: MP3, WMA; Photo: JPG, BMP
6. Video Decode----Video Decode: High Definition MPEG4 AVC/H. 264 HP-L4, MPEG-2 MP-HL/ML;
Aspect Ratio: Auto, 16: 9 Pillar box, 4: 3 Pan & Scan, 4: 3 Letter Box.;
Video Resolution: 1920X1080P
Shenzhen Maiyue Electronic Co., Ltd., specializing in the production of satellite TV receivers.
It was founded in 2004, specialized in DVB products, the factory employs more than 100 people, advanced production equipment and high-tech assembly line, and also quality control all products, based on time delivery of high quality products to ensure customers. Our main products include HD DVB-S2, HD DVB-T, and other high quality, reasonable price for our company by many customers. Our annual sales reach 10 million dollars. We goal is to provide high quality products and excellent after-sales service services. Meanwhile, we can cooperate in the OEM, ODM, and the SKD.
Advanced management mechanism, fill your order.
Here, we operate state of the most advanced machines, such as SMT equipment, pipeline equipment, in your order. 6 high-efficiency production plant in 2600 square meters of distribution lines support, we are willing to fill your large orders. Currently, all of our products to overseas markets, mainly due to south American, arab, African customers. Now we are looking for partners in the international market set-top boxes more customers
Operation and quality control procedures compatible with international standards.
According to ISO 9001: 2008 certification system, we assign each of our product line 2QC staff to closely monitor every step. We have 12 quality control personnel, some of whom have been in this field for 8 years. The operation of advanced testing, such as high / low temperature case, RoHS testing, high voltage tester, we can ensure that every unit you have high-performance, long life to equipment. For peace of mind, we even provide you with one-year warranty.
