Product Specifications
| Prod Model: |
FTTH |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Operating Temperature Range: |
-40 to +60 |
| Attenuation Coefficient: |
1310/1550nm≤0.34/0.20db/Km |
| Water Blacking Materal: |
Cable Jelly |
| Fiber Type: |
G652D |
| Central Strength Member: |
FRP |
| Out Sheath: |
HDPE |
| Application: |
Communication |
| Type: |
Single-mode Fiber |
| Certification: |
ISO9001 |
| Connection Structure: |
No |
Product Description
The optical fiber unit is positioned in the centre, two parallel fiber reinforced plastics FRP are placed at the two sides, then the cable is completed with a black or color LSZH Sheath
Our FTTH cable's Material of jacket is LSZH- LSZH cable
Optical fiber unit id positioned in the centre.
Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides.
A steel wire as the additional strength member is also applied,
The cable is completed with a black or color LSZH sheath.
Features:
Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber
Adopt fiber with small bending radius (G. 657), offering good bending resistance;
Simplified installation and maintenance, easy for splicing;
Easy cable stripping without need of tools, easy cable fixation and low cost of installation;
Suitable for termination at the field or factory pre-connectorized
Suitable for dropping in residential buildings, rat proof function, reliable and stable quality
Low smoke, zero halogen and flame retardant sheath
Fiber Type: G652D, 50/125, 62.5/125, G657A, G657A2, OM3-150, OM3-300, OM4
Jacket material: PVC, LSZH
Application:
Used as access building cable
Used in indoor cabling especially used for FTTH
