Full Color P8/P10 LED Display for Advertising

Product Specifications

Product Description

  Full Color P8/P10 LED Display for  Advertising

specification

Part Number:                                                     HERO-IDS4F-8S

Resolution :                                                         32(H)×16(V)

Pixel Pitch:                                                                8mm

LED Configuration:                                          1R1G1B 3-IN-1 SMD

Pixel Density:                                                      10,000pixels/ m2

Module Size:                                                       320*160mm

Driving IC:                                                         MBI5024

Driving Method:                                                   1/4 Scan, Constant Current

Cabinet Weight:                                                 42kg/sq.m.

Mechanical Ratings

Hanging Weight Support:                                     2T

Surface Flatness:                                                 Gap<0.5mm

Optical Ratings

Brightness:                                                         >1,800cd/ m2

View Angle:                                                        150°/150°

Gray Scale:                                                        8 bits input, correction with 14bits

Display COLOR:                                                      16.7M

Brightness Adjustment:                                           0~100%

Power Supply

Operation Power:                                             90~260V 50~60Hz

Max. Power Consumption:                                     600W/ m2

Average Power Consumption:                            200W/ m2

Control System

Control Mode:                                                     Synchronous display with control PC by DVI

Frame Update Frequency:                                    60~85Hz

Screen Refresh Frequency :                                   300~1000Hz

Gamma Correction:                                              -5.0~+5.0

Support Input:                                                   Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI

Control Distance:                                                     Ethernet cable<120m or Fiber Optic<10Km

Support VGA Mode:                                          1024×768, 1280×1024, 1600×1200, 1920×1280

Brightness Correction:                                             Pixel, Module, Cabinet

Environmental

Operating Temperature:                                   -20°~+60°

Operating Humidity:                                         10~95% RH

Operating Life:                                                  100,000hours

MTBF:                                                                 5000hours

Out of Control Rate:                                              <0.02%

Packing and transportation

Environmental carton, plywood case, flight case USE professional packaging.

The way of Packing can prevent the collision of LED screen effectively in the process of transportation, such as falling damage,etc.

Faultlessly solve your worries in the transportation.



About Hero

7-year's experience in LED screen industry, our factory has the ability of processing, researching and developing Led display to guarantee the prolificacy, a strict quality control process to make sure the quality of display screens.


Warranty

1. If the area is larger, we usually require customers or dealers to send someone to come to factory to study, training time a week, the main study screen operation, maintenance. Company training and providing accommodation are free of charge.

2. If the area is in more than 20 square meters of outdoor full color, it must have all accessories.

3. Response within 2 hours, non-artificial, general fault solution within 24 hours, and acceptable failure resolved within 48 hours.
