Elecsound offer very good prices for cermet trimming potentiometers. Good quality, fast delivery. 3006, 3262, 3266, 3314, 3224, 3269, 3296, 3299, 3303, 3306, 3309, 3318, 3323, 3329, 3362, 3386, 3 540 and 3590
Standard items for ET3296 Cermet Trimming Potentiometer
ET3296 Trimming Potentiometers ET3296P-1-100 10 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-200 20 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-500 50 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-101 100 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-201 200 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-501 500 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-102 1000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-202 2000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-502 5000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-103 10000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-203 20000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-503 50000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-104 100000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-204 200000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-504 500000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-105 1000000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296P-1-205 2000000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-100 10 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-200 20 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-500 50 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-101 100 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-201 200 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-501 500 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-102 1000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-202 2000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-502 5000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-103 10000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-203 20000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-503 50000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-104 100000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-204 200000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-504 500000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-105 1000000 ohm RoHS Elecsound
ET3296 Trimming Potentiometers ET3296Z-1-205 2000000 ohm RoHS Elecsound
Trimming potentiometer
ET3006 Trimming Potentiometer
ET3262 Trimming Potentiometer
ET3266 Trimming Potentiometer
ET3314 SMD trimmig potentiometers
ET3224 trimmig potentiometers
ET3269 Trimming Potentiometer
ET3296 Trimming Potentiometer
ET3299 Trimming Potentiometer
ET3303 SMDTrimming Potentiometer
ET3306 6mmTrimming Potentiometer
ET3309 6mm Trimming Potentiometer
ET3318 6mm rTrimming Potentiometer
ET3323 Trimming Potentiometer
ET3329 Trimming Potentiometer
ET3362 Trimming Potentiometer
ET3386 Trimming Potentiometer
ET3540 WireWound Potentiometer
ET3590 22mm Potentiometer
| Square/Multiturn/ Cermet/ Industrial/ Sealed |
| 5 Terminal Styles |
| Rohs Compliant |
|
| Electrical Characteristics |
| Standard Resistance Range: 10Ω - 2MΩ |
| Resistance Tolerance: ±10% std. |
| Absolute Minimum Resistance: ≤1% or 2Ω |
| Contact Resistance Variation: ≤1% or 1Ω |
| Insulation Resistance : R1≥1,000 MegΩ |
| Withstand Voltage : 640VAC |
| Effective Travel: 28 turns normal |
| Environmental Characteristics |
| Power Rating:(350V max.)0.5W@70ºC, 0W@150ºC |
| Temperature Range: -55ºC to +150ºC |
| Temperature Coefficient: ±100ppm/ºC |
| Vibration: 10-500Hz, 0.75mm, 6Hour: R≤±5% |
| Shock: 390m/s, 4000cycles, R≤±5% |
| Electrical Endurance:0.5W@70ºC,1000H,R≤10% |
| Rotational Life: 200Cycles,R≤±5% |
| Physical Characteristics |
| Starting Torque: ≤35mN·m |
| Flammability: UL.94V-0 |
| Marking: Resistance code, Model |
| Standard Packaging: 50pcs per tube |
