| Overall Data |
| Bucket Capacity (m3) | 0.5 |
| Rated Payload (kg) | 1200 |
| Operating Weight (kg) | 4350 |
| Traction Force (kN) | 31 |
| Breakout Force (kN) | 36 |
| L×W×H(mm) | 5376×1630×2600 |
| Travel Speeds (km/h): |
| I | II |
|
| Forward | 8.3 | 20.8 |
|
| Reverse | 8.3 | 20.8 |
|
| Engine | CHANGCHAI-490B |
| Rated Power (kW·hp)/rpm) | 38·(52)/2400 |
| Rated Torque (Nm/rpm) | 173/1800 |
| Starting Voltage (V) | 24 |
| Drive Train |
| Torque Converter | Single-stage, Single-turbine, 3-element |
| Torque Ratio | 3.7 |
| Transmission | Fixed Shaft Hydraulic Shift Spur Gear |
| Gear | 2F/2R |
| Pressure of Transmission (MPa) | 1.2-1.5 |
| Main Reducer | Spiral Bevel Gear Single-stage Reduction |
| Final Reducer | Planetary Reduction |
| Tire | 11.00-16 |
| Brake System |
| Service Brake | Air Drive, Four Wheel Brake (Dry) |
| Setting Pressure (MPa) | 0.78 |
| Parking & Emergency Brake | Flexible Shaft Controlled Caliper |
| Steering System |
| Type Hydraulic Load Sensor System |
| Cylinders-bore x Stroke (mm) | 2-63X280 |
| Steering Pump Shared With Working Pump |
| System Pressure (MPa) | 14 |
| Steering Angle | ±35° |
|
| Hydraulic System |
| Lift Cylinders-bore x Stroke (mm) | 2-80X610 |
| Tilt Cylinder-bore x Stroke(mm) | 1-100X450 |
| Working Pump | Gear Pump |
| Flow Rate (L/min/rpm) | 120/2400 |
| System Pressure (MPa) | 16 |
| Hydraulic Cycle Time, Rated Load in Bucket (In Second): |
| Raise(Loaded) | Dump | Lower(Empty) | Total |
| 4.5 | 1.2 | 2.2 | 7.9 |
| Electrical System |
| System Voltage (V) | 24 |
| Battery(2 in series) (Ah) | 180 |
| Lamp Voltage (V) | 24 |
| Service Refill Capacity |
| Fuel Tank (L) | 80 |
| Hydraulic Tank (L) | 80 |
| Transmission (L) | 16 |
| Front Axle (L) / Rear Axle (L) | 88 |
