Product Specifications
| Prod Model: |
1x2 optical coupler |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
ISO9001: 2008 |
| Package: |
Steel Tube |
| Support Network: |
Communication Cable |
| Usage: |
Telecommunication |
| Type: |
Passive Components |
Product Description
1x2 Fused Coupler, optical coupler, coupler for GPON/EPON
Flyin supply fused coupler for GPON, EPON and other optical network with high quality and competitive price.
Key Features:
1. Low Insertion loss
2. High Return Loss
3. Option Coupling Ratio
4. Wide Operating Temperature
5. Excellent Environmental & Mechanical Stability
6. Qualified Under Telcordia GR-1221 and GR-1209
Applications:
1. FTTX (FTTP, FTTH, FTTN, FTTC)
2. Passive Optical Networks (PON)
3. Local Area Networks (LAN)
4. EDFA systems
5. Test Equipments
|
Coupling Ratio |
Insertion Loss |
|
P Grade |
|
50/50 |
4.1/4.1 |
|
40/60 |
5.2/3.2 |
|
30/70 |
6.5/2.5 |
|
20/80 |
8.5/1.85 |
|
10/90 |
12/1.33 |
|
PDL |
0.15 |
|
Operation Wavelength |
850± 40, 1310± 40, 850/1310± 40 |
|
Directivity |
≥ 40 |
|
Return Loss |
≥ 40 |
|
Channel Number |
1× 2 or 2× 2 |
|
Parameter |
Unit |
Specification |
|
Operating Wavelength |
nm |
850± 40, 1310± 40, 850/1310± 40 |
|
1× N |
|
N=4 |
N=5 |
N=6 |
N=8 |
N=16 |
N=32 |
|
Fiber Type |
|
Corning MMF 62.5/125um or 50/125um |
|
IL(MAX) |
dB |
8.0 |
9.0 |
10.0 |
11.0 |
15.0 |
19.0 |
|
Uniformity |
dB |
1.0 |
1.0 |
1.5 |
1.5 |
2.0 |
2.5 |
|
Return Loss |
dB |
≥ 40 |
|
Directivity |
dB |
≥ 40 |
Environmental Conditions:
|
Operating Temperature |
|
-20 to +70 |
|
Storage Temperature |
|
-40 to +85 |
|
Operating Humidity |
%RH |
≤ 93 |
|
Storage Humidity |
%RH |
≤ 93 |
