G128 Series Marine Diesel Engine for Diesel Generator Set

Name: G128 Series Marine Diesel Engine for Diesel Generator Set
Brand: china-manufacturer-directory.com
SKU: 698358872
Availability: InStock
Rating: 4.3 (100 reviews)

Supplier:	Shanghai Stanford Power Equipment Co., Ltd.
Price:	US $ 10000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	G128Ca
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Weight:	1200kg
Type:	Self-Starting Diesel Generator
Installation Method:	Fixed
Stroke:	Four Stroke
Cooling Method:	Water Cooling
Output Type:	AC Three Phase

Product Description

The marine diesel engine made by our institution can be used as both main and auxiliary engine power, and match with all kinds of gearboxes of Hangzhou Gearboxes Factory. It adopts a seawater and fresh water dual-cooling closed circle system and water-cooled vent pipes. Supercharged type adopts branch vent pipes and its supercharger has thermal shrouds to prevent the safety of uses. And they can be equipped with electronic monitoring device and control wire according to user demands. The patrol boats of Shanghai Ocean Inspection Bureau are our marine diesels in trust.
The marine machine sets are equipped with sea water pumps, disc rheostats, applicable to ship repair and offshore petroleum exploration, and are ideal substitutes of battery ships.

Marine diesel engine
Engine Power: 128.5-254.8KW
Inline, direct, injection4-stroke,
Rated speed: 1500/1800rmp
Tubocharged/T intercooled

Model	G128Ca	G128ZCa	G128ZLCa	G128ZLCa1	G128ZLCa2	G128ZLCa4
Type	lnline,direct,injection,4-stroke,water cooled
Inspiration	Nature intake	Tubocharged	Tubocharged/Tubocharged intercooled
Number of cylinders	6
Bore (mm)	135
Stroke (mm)	150
Displacement (L)	12.9
Firing Order	1-5-3-6-2-4
Cinoressuib Rotio	17
Overload Power (kW/HP)	147.1/200	178.2/242	206/280	220.5/330	260/353	283/385
Overload speed (rmp)	1854	1545				1854
Rated Power (kW/HP)	133.7/182	162/220	187/254	200.5/273	236/320	257/350
UNA Rated Power (kW/HP)	128.5	155.5	180	193	222	254.8
Rated Speed (rmp)	1800	1500				1800
Min.Fuel Comsumption (g/kW.h)	≤197
Lubricating Oil Comsumption (g/kW.h)	≤0.7
Idling Speed (rmp)	650±30
Starting Method	Electric Start(DC24V)
Overall Dimension (mm)	1633×853×1217	1730×845×1300	1672×812×1521		1762×811×1521	1762×811×1532
Net Weight (kg)	1050±50			1200±50		1300±50

Shanghai Stanford Power Equipment Co., Ltd. is a professional manufacturer of 135 series diesel engines, 135 modified products and subsequent auxiliary products (diesel generating sets). In the business concept of People-oriented, our institution employs high-paying key technicians of all kinds, cultivates a strong technical team, and is kind to the employees to stimulate their passion at work. According to customer requirements, our institution is able to design different stationary, marine and power station diesel engines in line with the international standards.

Please feel free to contact us for further information.
