Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Gelin |
| Usage: |
Mining Concentration |
| Capacity: |
0.6~80tons Per Hour |
| Feeding Density: |
30%~50% |
| Testing: |
Supply |
| Guarantee: |
1year |
| After Service: |
Supply |
| Delivery Date: |
15days |
| Place Of Origin: |
China |
| Type: |
Mineral Processing & Screening Equipment |
| Condition: |
New |
Product Description
1). High recovery ratio 90% above 2). Application: Alluvial gold, river sand gold, rock stone gold, fine sand gold 3). Guarantee 12 months 4). Produced by China biggest gravity mining machine factory.
Gold mat, gold grass carpet, gold sluice box with gold mat for gold ore capture.
Thickness: 25mm
65kgs for 1 roll
One important usage of PE lawn mat is for gold rushing, the quantity of grass is higher, high density of piles, the bottow of the lawn lined with hard -wearing plastic, every plant of the lawn has a square groove, which can help to collect and keep the golden, the rate of the golden will add about 20% to 40%, which is mainly for the golden regions.
Knelson centrifugal gold concentrator:
STLB Centrifuge is kind centrifugal concentration equipment. It can be used not only for placer gold mining, but also for hard rock mining to recover the natural gold, replacing amalgamation. It is also used to recover gold from the old tailings.
Four models are available. Application shows that the recovery can be as high as 99%, especially for the case in recovering the natural gold in lode ore with 65% of the ore having a milling size of 0.074mm, the recovery for the natural gold is expected up to 98%, For that natural gold of 0.004mm in particle size, the recovery is 97%. The cleaning up cycle is 1~4 hours, and the upgrade ratio is up to 1, 000 times. The equipment is patented in China.
The STL Centrifuge will separate any heavy material from any light material so long as there is sufficient difference in the densities of the individual particles in question. The Concentrator can treat particle sizes from below 10 microns up to a maximum of 6mm and is most commonly used for recovery in Gold and Platinum. Other recovery uses include Mercury, Palladium, Tantalum, Copper, Silver and Diamond Indicator Minerals.
Rugged design and a high degree of quality manufacturing ensures that every Concentrator will provide many years of reliable, trouble-free operation in even the most severe operating environments.
Welcome to visit our factory in your free time!
|
Model |
STLB20 |
STLB30 |
STLB60 |
STLB80 |
STLB100 |
|
Feeding Capacity(t/h) |
0-0.6 |
2-3 |
8-12 |
35-45(solids) |
70-80 |
|
Fluidization water Required(m 3 /h) |
2-3 |
3-5 |
7-10 |
30-36 |
55-80 |
|
Slurry Water Required(m 3 /h) |
1.5-4 |
5-7 |
8-12 |
35-50 |
70-120 |
|
Feeding Density(%) |
0-50 |
0-50 |
0-50 |
0-50 |
0-50 |
|
Feeding size(mm) |
0-3 |
0-3 |
0-5 |
0-5 |
0-5 |
|
Concentration Cleaning Up Cycle |
Vein gold 1-3 Hours Placer gold " 2-6 Hours |
|
Concentrate weight(kg) |
2 |
10-20 |
30-40 |
60-70 |
80-90 |
|
Power Requirements(Kw) |
0.75 |
1.5 |
4 |
11 |
22 |
|
Approximate shipping weight(Kg) |
145 |
400 |
1000 |
1500 |
2000 |
|
Approximate created shipping Dimensions (mm) |
790*785*790 |
1180*1140*1250 |
1970*1670*1750 |
2300*1800*2200 |
2400*2000*2300 |
Ganzhou Gelin Mining Machinery Company Limited is an expert manufacturing mining machines in China. Our company is located in the Industrial Zone of Shicheng County, Jiangxi Province.
Our distinctive products include Shaking table, Jig, Spiral separator, Gold concentrator, Ball mill, Jaw crusher, flotation, magnetic separator, Feeder, Classifier, ore washing machine and lab equipment etc. Our machines are popular in separating gold, copper, manganese, chrome, tungsten, tin, nickel, iron, titanium, lead, zinc, tantalum and some non-ferrous metals like quart, zircon, barite, etc.
Our products are sold to more than 28 provinces/cities in China and are exported to Russia, Africa, India, the Middle East, the Philippines, Mongolia, Sudan, Kazakhstan, Brazil, America, Canada and Australia. We have won high reputations from all of our clients for our machines and services.
Besides the above mentioned products, we can also design and manufacture many kinds of special mining machines and automatic processing lines according to the requests of customers. If you are in need of detailed information, please inform us. We will provide you with total solutions according to your specific requirements in time.
As a leading provider of mining machines in China, we will continue to do our best to offer customers the best quality products and services at competitive prices, to meet variable challenges and keep advantageous.
