Electric Galvanized Chain Link Fence/Dog Kennel links (chain link fence 05)
Product name: Electric galvanized chain link fence, galvanized cahin link fence, chain link fence, galvanized diamond fence
Material: Galvanized iron wire
Electro galvanized chain link fence:
1. Mesh/inch: 1", 1.5"2", 2.25", 2.4", 2.5", 3".
2. Wire gauge: BWG8-14
3. Wire dia(mm): 1.60-4.2
4. Nominal weight(kg/sq m): 0.8-4.5
5. Fabric: Fine low-carbon steel wire, stainless steel wire, aluminum alloy wire and PVC-coated wire.
6. Weave and Features: Crocheting makes even, plain and good looking mesh. Thick wire makes long life, simple but beautiful and useful design.
7. Use: Chain link fence is widely used, such as fence for fowl breeding, guard for machines, fence for express way, stadium, city road and green belts, cages for sea dike, hill side, road, reservoir or other civil engineering, craft art, and conveyer belt.
[Inner Wire Material]
1. Black wire: just black wire, without any surface finish.
2. Electro galvanzied, hot-dipped galvanzied
[Two standard zinc coating for hot-dipped galvanzied]
1) normal zinc coating(50-60g/m2)
2) heavy zinc coating(260g/m2)
Tips: Hot-dipped galvanized has better corrosion resistance than electro galvanized, because the thickness of zinc coating is thicker.
Maishi provide Real quality, reasonable price and expert service! Which must be satisfied you!
| Mesh | Standard Wire Gauge (SWG) | Wire Diameter (mm) | Nominal Weight (kg/m2) |
| Inch | mm |
| 1/2 | 12.70 | 14 | 2.2 | 4.4 |
| 3/4 | 19.05 | 12 | 2.8 | 6.0 |
| 3/4 | 19.05 | 14 | 2.2 | 3.3 |
| 3/4 | 19.05 | 16 | 01.63 | 1.9 |
| 1 | 25.40 | 12 | 2.8 | 4.0 |
| 1 | 25.40 | 14 | 2.2 | 2.4 |
| 1 | 25.40 | 16 | 01.83 | 1.4 |
| 5/4 | 31.75 | 12 | 2.8 | 3.2 |
| 5/4 | 31.75 | 14 | 2.2 | 01.92 |
| 3/2 | 38.10 | 10 | 03.25 | 4.1 |
| 3/2 | 38.10 | 12 | 2.8 | 2.7 |
| 3/2 | 38.10 | 14 | 2.2 | 1.6 |
| 2 | 50.80 | 8 | 04.06 | 4.6 |
| 2 | 50.80 | 10 | 03.25 | 3.1 |
| 2 | 50.80 | 11 | 02.95 | 2.5 |
| 2 | 50.80 | 12 | 2.8 | 2.0 |
Selvedge Twist Methods: We supply knuckled or Barb selvedge below.
MOQ:50rolls
Payment term:30%T/T in advance and balance against of B/L copy within 5days.
Packing:pvc woven cloth on both ennds, custome packing available at request
[Uses] Prevention for road, railway, airport, residence district, seaport, garden, feeding and husbandry.
Also used in breeding of animals.
Information required for quotation:
1.Material
2.Mesh size
3.Wire diameter
4.Width and Length
5.Required weight per roll
6.Quantity
