Product Specifications
| Prod Model: |
GTY100 |
| Markets: |
North America,South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Walking Mode: |
Crawler |
| Certification: |
ISO9001: 2000 |
| Condition: |
New |
Product Description
Dry Ground Use ~~ GTY100 Hydraulic Bulldozer
Main features:
1.The bulldozer use Deutz engine with domestic-2 emission standard. It is strong power,energy saving and
large torque reserve.
2.Using integrated instrument with beautiful appearance and easy maintenance.
3.Using tetrahedron cabin with streamline shape,the machine has an open vision,comfortable driving and
beautiful appearance.
4.Straight tilt blade is standard configuration with easy adjustment and high efficiency.
Technical Parameter:
| 1 | Model. | / | GTY100 |
| 2 | Total weight | kg | 10500 |
| 3 | Diesel Engine Model. | mm | Weichai Deutz WP6G |
| 4 | Rated power/speed | kw/r/min | 82/2200 |
| 5 | Fuel consumption | g/kw.h | <210 |
| 6 | Forward 3 Gear | Km/h | 3.03~9.63 |
| 7 | Reverse 3 Gear | Km/h | 3.79~12.03 |
| 8 | Width of Track shoes | mm | 450 |
| 9 | Land pressure | kpa | 54.2 |
| 10 | Overall size L*W*H | mm | 4130*2930*3130 |
| 11 | Blade type | | Straight |
| 12 | Bulldozer width | mm | 2930 |
| 13 | Bulldozer height | mm | 960 |
| 14 | Blade max. lifting height | mm | 830 |
| 15 | Blade max. digging height | mm | 350 |
| 16 | Twing equipment/scarifier(optional) | | Fixed /3-teeth |
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
