Main technical parameter:
1. Output paper: Kraft paper, carton paper,
2. Raw material: Waste paper
3. Capacity: 55-60T/d
4. Output paper weight: 110-240G/M2
5. Net paper width: 2400mm
6. Cylinder mould width: 2850mm
7. Rail space: 3400mm
8. Output paper humidity: 4%~8%
9. Working Speed: 80-120m/min
Main frames of the production line:
Main equipment's construction:
1. Cylinder part: Φ 1500mm× 2850mm cylinder mould 3sets; Φ 450mm× 2850mm couch roll 3sets; Reverse roll 1 set; Rubber Share hardness is 38º C± 2, pneumatic pressure device.
2. Press part: Φ 600mm× 2850mm stone roll 1 set; Φ 550mm× 2850mm rubber roll 1 set; 500 speed reducer of drive part 1 set; Scraper knife 1 group.
3. Dryer part: Φ 2500mm× 2850mm Dryer can 2 sets; Φ 1500mm× 2850mm Dryer can 8 sets; Φ 550mm× 2850mm touch roll 2 sets; Rubber Share hardness is 95º C± 2, pneumatic pressure device
4. Winding part:
Cylinder type winding machine 1 set, Rewinding machine 1 set.
5. Driving & control part:
AC frequency conversion speed, section drive.
|
No. |
equipment |
QTY |
|
1 |
2400mmPaper making machine
|
1 set |
|
2 |
dryer can Exhaust hood
|
1 set |
|
3 |
850axial flow ventilator
|
3 sets |
|
4 |
Φ1500mm Pressure type mesh vat
|
1 set |
|
5 |
Model 15roots pump
|
1 set |
|
6 |
suction box |
3 sets |
|
7 |
2400mm Winding machine
|
1 set |
|
8 |
calendar |
1 set |
|
9 |
Rewinding machine
|
1 set |
|
10 |
5m 3 high consistency Hydrapulper
|
2 sets |
|
11 |
Fiber separator |
1 sets |
|
12 |
Pressure screen |
1 set |
|
13 |
2m 2 High frequency vibration screen
|
2sets |
|
14 |
Φ450Double disk pulp refiner
|
3 sets |
|
15 |
12m 2 Pulp thickener
|
1 set |
|
16 |
Φ700mmThruster
|
6 sets |
|
17 |
4 inch Pulp pump
|
4 sets |
|
18 |
6 inch Pulp pump
|
6 set |
|
19 |
8 inch Pulp pump
|
4 set |
|
20 |
Japan Sanken Control cabinet
|
1 set |
|
21 |
air pump cabinet |
1 set |
|
22 |
Work table |
1 set |
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
