H61-1155 Computer Peripheral Motherboard with Intel H61 Express Chipset

Product Specifications

Prod Model:	H61-1155
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	H61-1155
Northbridge:	Intel H61 Express Chipset
Southbridge:	Intel+Ich8
LAN:	Realtek Rtl81xx(10/100/1000 Mbit)
Audio:	Realtek Alc662, Supports High Definition
Shipping Way:	DHL /UPS / FedEx
Shipping Time:	2-4 Working Days
Payment:	Paypal/ T/T/ Wester Union
Products Logo:	for Your Optional
Main Chipset:	Intel
Structure:	Micro ATX
Memory:	DDR3
CPU Socket:	LGA 1155

Product Description

H61-1155 Computer Peripheral Motherboard with Intel H61 Express Chipset

CPU

LGA1155, supports Intel Core i7 / Intel  Core i5 / Intel Core i3 / Intel Pentium / Intel Celeron CPU

for other Intel  Core CPUs with External video card

Chipset

Northbridge: Intel H61 Express Chipset

Southbridge: Intel+ICH8

Memory

2x1.5V DDR3 DIMM, maximum capacity to 8G

Dual channel  1333/1066/800 MHz

Graphics

1*HDMI port(option)

1*VGA port

Audio

Realtek ALC662, supports High Definition

supports Audio 2/4/5.1 sound channel

LAN

Realtek RTL81XX(10/100/1000 Mbit)

Expansion Slot

1*PCI Express x16(supports PCI Express 3.0 with the Intel 22nm series CPU

2*MINI PCI Express x1(supports PCI Express 2.0)

Internal slots

4*SATA, 3Gb/s

1*CPU fan

1*system fan

1*control board slot

1*sound source slot

2*USB2.0/1.1(for 4 USB slots)

1*COM(RS232)

Back slots

1*PS/2 keyboard slot

1*PS/2 mouse slot

1*VGA

4*USB 2.0/1.1 ports

Accessories

CD DRIVER, BACK PANEL,MANUAL,SATA CABLE,IDE CABLE.

SIZE

230mm x 165mm

PACKING

20PCS IN ONE CARTON
