Hand tapsmade from HSS. We can supply any specification you need.
1. Fluteless
2. Taps do not produce chips
3. Precise uniformity of tapped thread limit
4. Excellent rigidity
5. Protect surface hardness
6. High roughness and high intension thread
HSS-Co machine taps
TiN/TiAlN coated or not
Spiral flute taps or roll forming taps
For blind hole or through hole tapping
Variety:
7. Roll forming threading taps- HSS-Co ground thread
8. Spiral flute threading taps- HSS-Co ground thread
Taps Limits: 2H, 3H, 4H, 5H, 6H, 7H
Tolerance: 6G/6GX, 6H/6HX
Surface treatment: TiAlN, TiN coating
Tap hardness: HRC 64-65
For Aluminum alloy, Steel, Cast iron, Stainless steel etc materials processing
|
Size |
Overall Length |
Flute Length |
Size |
Overall Length |
Flute Length |
|
M1*0.25 |
32 |
5.5 |
M10*1.5 |
70 |
24 |
|
M1.1*0.25 |
32 |
5.5 |
M11*1.5 |
70 |
24 |
|
M1.2*0.25 |
32 |
5.5 |
M12*1.75 |
75 |
29 |
|
M1.4*0.3 |
32 |
7 |
M14*2.0 |
80 |
30 |
|
M1.6*0.35 |
32 |
8 |
M16*2.0 |
80 |
32 |
|
M1.7*0.35 |
32 |
8 |
M18*2.5 |
95 |
40 |
|
M1.8*0.35 |
32 |
8 |
M20*2.5 |
95 |
40 |
|
M2*0.4 |
36 |
8 |
M22*2.5 |
100 |
40 |
|
M2.2*0.45 |
36 |
9 |
M24*3.0 |
110 |
50 |
|
M2.3*0.45 |
36 |
9 |
M27*3.0 |
110 |
50 |
|
M2.5*0.45 |
40 |
9 |
M30*3.5 |
125 |
56 |
|
M2.6*0.45 |
40 |
9 |
M33*3.5 |
125 |
56 |
|
M3*0.5 |
40 |
11 |
M36*4.0 |
150 |
63 |
|
M3.5*0.6 |
45 |
13 |
M39*4.0 |
150 |
63 |
|
M4*0.7 |
45 |
13 |
M42*4.5 |
150 |
63 |
|
M4.5*0.75 |
50 |
16 |
M45*4.5 |
160 |
70 |
|
M5*0.8 |
50 |
16 |
M48*5.0 |
180 |
75 |
|
M5.5*0.9 |
50 |
18 |
M52*5.0 |
180 |
75 |
|
M6*1.0 |
50 |
19 |
M56*5.5 |
200 |
85 |
|
M7*1.0 |
50 |
19 |
M60*1.25 |
200 |
85 |
|
M8*1.25 |
56 |
22 |
M64*6.0 |
220 |
90 |
|
M9*1.25 |
63 |
22 |
M68*6.0 |
220 |
90 |
Yangzhou Jiangwei Tool Co., Ltd. (formerly: Jiangdu Nanxing Tool Factory) is located in Jiangdu, the eastern suburbs of Yangzhou, a famous historical and cultural city with beautiful scenery. South of Yangtze River, close to Beijing-Shanghai, Tongjiang-Sanya, Yangzhou-Liyang Expressways, Nanjing-Nantong 328 National Highway, Nanjing-Qidong Railway, our company enjoys a superior geographical and traffic position. Jiangsu Yangzhou Jiangwei Tool Co., Ltd. is a private industrial and trading enterprise integrating design, production and sales. With long years of experience of producing cutting tools, we mainly manufacture straight-shank twist drills, drill, double-headed drills, lengthened drills, parabolic depth drills, equal-shank drills, equal-shank woodworking drills, machine screw taps, hand screw taps, opening machine, and high-speed steel circular turning tools (needles) etc. Besides a complete variety and prompt delivery, we can customize non-standard products according to the map and sample required by customers. We have a strong technical force and advanced production testing equipment, which can ensure the stable and excellent quality of all products. From raw materials into the factory, the production process to the product packaging and sales service, we all have a comprehensive and strict quality management system. We are continuing efforts to improve and innovate our products, while our factory has more than one brand so as to meet various needs of different users. We have won the trust and support from the majority of customers because of our high-quality products and good reputation. Our company will always adhere to the enterprise purpose of "seek survival on quality, promote development on innovation, pursue credibility on service", and commit ourselves to the unswerving innovation for our prosperity and development. We are willing to cooperate in good faith with colleagues at home and abroad to create a more brilliant tomorrow!
