HASL Lead Free PCB Circuit Board for Industrial Control Used

Name: HASL Lead Free PCB Circuit Board for Industrial Control Used
Brand: china-manufacturer-directory.com
SKU: 763205115
Availability: InStock
Rating: 4.9 (78 reviews)

Supplier:	Fastline Circuits Co., Limited
Price:	US $ 0.21/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,EXW

Product Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Board Thickness:	1.6mm
Copper Thickness:	1oz
Material Type:	Fr4
Surface Treatment:	HASL Lead Free
Solder Mask:	Green, Red, Blue, Black
Silk Screen Color:	White
Board Layer:	1-50
Shipping Type:	DHL, UPS, TNT, EMS, FedEx etc
Packing Type:	Carton + Vacumm
Lead Time:	5-7 Days
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Flame Retardant Properties:	V1
Base Material:	Fr4
Brand:	Fastline

Product Description

Product Description

High Frequency Prototype PCB Manufacture Multilayer PCB Circuit Board for Industrial Control Used

This is a type of FR-4 PCB for the application of Industrial Control. It's a 2 layer board at
3.2mm thick. The base laminate is from ITEQ, Solder mask and silkscreen from Kuangshun and
Taiyo. It's fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels
are packed separately.

Parameters & Data Sheet

PCB SIZE	79 x 32mm=1PCS
BOARD TYPE
Number of Layers	4 layers
Surface Mount Components	NO
Through Hole Components	YES
LAYER STACKUP	copper ------- 216um(6oz)+plate TOP layer
	FR-4 2.8mm
	copper ------- 216um(6oz)+plate BOT Layer
TECHNOLOGY
Minimum Trace and Space:	14 mil/29 mil
Minimum / Maximum Holes:	0.55/15.0mm
Number of Different Holes:	12
Number of Drill Holes:	431
Number of Milled Slots:	0
Number of Internal Cutouts:	0
Impedance Control	no
BOARD MATERIAL
Glass Epoxy:	FR-4, ITEQ IT-140 TG>135, er<5.4
Final foil external:	6oz
Final foil internal:	0oz
Final height of PCB:	3.2mm ±0.32
PLATING AND COATING
Surface Finish	Hot air soldering leveling(HASL), lead free, Sn>=2.54µm
Solder Mask Apply To:	Top and Bottom, 12micron Minimum
Solder Mask Color:	Blue, KSM-6189BL04, Kuangshun supplied
Solder Mask Type:	LPSM
CONTOUR/CUTTING	Routing
MARKING
Side of Component Legend	TOP
Colour of Component Legend	White, IJR-4000 MW300, Taiyo Supplied.
Manufacturer Name or Logo:	Marked on the board in a conductor and leged FREE AREA
VIA	Plated Through Hole(PTH)
FLAMIBILITY RATING	UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension:	0.0059" (0.15mm)
Board plating:	0.0030" (0.076mm)
Drill tolerance:	0.002" (0.05mm)
TEST	100% Electrical Test prior shipment
APPLICATION:	Power Inverters Switching Power Supply Solar Inverter Invertor Grid Tie Inverter Tattoo Power Supply
TYPE OF ARTWORK TO BE SUPPLIED	email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA	Worldwide, Globally.
