Hcc3100 2d Barcode Scanner
Product Specifications
| Prod Model: |
HCC3100 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Image Size: |
752*480 |
| Dimension: |
95.0 * 70.0 * 160.0 Mm |
| Weight: |
128g |
| Certification: |
FCC |
| Type: |
Data Collector |
Product Description
1. Support 1D and 2D barcode scanning
2. Provide rich interface choose, like RS232, USB HID-KBW, USB Data Pipe, USB COM Port, HID-POS and so on
3. Fully consider the human body engineering of the shape design, and convenient and fast
4. Read barcode symbology on phone screen
5. Antiknock design: Withstand 1.5M drops
6. Support 20 countries keyboard languages
7. Service life of button reaches up to 50 million times
| Performance |
| Image Sensor | CMOS |
| Image Size | 752*480 |
| Support Interface | RS232, USBHID-KBW, USBDataPipe, USBCOMPort, HID-POS |
| Barcode Scanning Parameter |
Symbologise | 2D
2D |
DF417, QRCode(Model1/2), DataMatrix(ECC200, ECC000
, 050, 080, 100, 140), Aztec, Maxicode, etc |
1D
1D | Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codaba
r, In-terleaved2of5, ISBN, Code93, UCC/EAN-128, GS1Data
bar, etc |
| Precision | ≥ 4mil |
| Depth of Scan Field | 35mm-210mm |
| Print Contrast Signl | ≥ 30% |
Sensitivity | Roll | 360° @ 0° Pitch and 0° Skew |
| Skew | ± 60° @ 0° Roll and 0° Pitch |
| Pitch | ± 60° @ 0° Roll and 0° Skew |
| Lighting Performance Parameter |
| Light Source | LED (622 nm - 628 nm) |
| Light Intensity | 330 LUX (130 mm ) |
| Physical/Electrical Parameter |
| Power Consumption | 2W |
| Voltage | DC 5V (4.5-5.5V) |
Current | Working | 400mA |
| Idle | 115mA |
| Battery Duration | 18mA |
| Deep-sleeping | 800uA |
| Dimension | 95.0 * 70.0 * 160.0 mm |
| Weight | 128g |
| Environment |
| Operate Temperature | -5º C- +45º C |
| Storage Temperature | -40º C- +60º C |
| Humidity | 5% - 95% (non-condensing) |
| Illumination | 0 ~ 100, 000 LUX |
| National Certification | FCC Part15 Class B, CE EMC Class |
Shenzhen HCC Technology Co., Ltd, established in 2008 year, is a professional manufacturer engaged in the research, development, production, sale and service of Intelligent Commercial Equipment, such as:
Multi-payment product line -- Handheld POS terminal, Retail POS, mPOS etc.
Automatic Fare Collection (AFC) product line -- Bus validator machine and system etc.
E-commerce Logistics and IOT industry product line -- Handheld PDA, Mobile printer, Barcode scanner / printer, RFID device etc.
Our factory had obtained ISO9001 certificates over 15 year, and production department is over 3, 000 SQM. We are also professional in OEM and ODM service, welcome to customize and develop the smart device to meet customers' indeed application.
Most of our products have passed CE/FCC/RoHS international standard, and also approved by Unionpay, EMV, PCI, Visa, MasterCard Industry Professional Certifications, which greatly ensure the highest level safety and quality of our products.
In the past 11 years, we have deepened in printing and payment industry and expanded markets in Southeast and Central Asia, Middle East Asia, South America, Africa and Europe etc. Our products obtain sustained growing market share, and exported to clients over 100 foreign countries and regions.
Our company's slogan is "Professional Solution Provider for Intelligent Commercial Equipment --- Smart and Reliable".
Shenzhen HCC sincerely wish to cooperate with your esteemed company, and provide most suitable products and solution to your customers. We co-create one more Intelligent and glamorous business world.
Business Type: Manufacturer/Factory
Management System Certification: ISO 9001,HACCP
International Commercial Terms: FOB, CFR, CIF, DAT, FAS, DDP, DAP, EXW
Terms of Payment: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
Average Lead Time: Peak season lead time: within 15 workdaysOff season lead time: within 15 workdays
Number of Foreign Trading Staff: 21~50 People
Export Year: 2008-03-05
Export Percentage: 71%~90%
Main Markets: South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Export Mode: Have Own Export License
Factory Address: Rm. 306, 3/F, Bldg. 6, Changyuan New Material Port, No. 2 Gaoxin C. Ave. 1st, Nanshan Dist, Shenzhen, Guangdong, China
R&D Capacity: OEM, ODM, Own Brand(HCCTG)
No. of R&D Staff: 5-10 People
No. of Production Lines: 6
Annual Output Value: US$10 Million - US$50 Million
