Product Specifications
| Prod Model: |
KG690 |
| Markets: |
Eastern Europe,Western Europe |
| Response Time: |
0.7 |
| Image Size: |
8MP;5MP;3MP |
| Triggering Interval: |
1sec-60min Programmable |
| Operating Temperature: |
-20-60°c(Storage Temperature:-30-70°c) |
| Operating Humidity: |
5%-90% |
| IR-Flash Range: |
20m-25m |
| IR LED: |
36PCS IR LED |
| Timed Scan: |
2X;Programmable |
| Shutter Speed: |
1/10-1/2000s |
| Security Authentication: |
FCC/CE/RoHS/Weee |
| Megapixel: |
5.0-9.9MP |
| Image Sensor: |
3CMOS |
| Memory Card Type: |
SD Card |
| Screen Type: |
Dual Screen |
| Screen Size: |
>3" |
| Optical Zoom: |
Fixed Focus |
| Video Capture: |
Video Capture |
| Image Stabilization: |
Image Stabilization |
| Red-Eye Reduction: |
Without Red-Eye Reduction |
| External Flash: |
Without External Flash |
| WiFi: |
Without WiFi |
| Type: |
Hunting Camera |
| Viewfinder Type: |
Wildlife or Outdoors |
| Lens: |
Custom Lens |
Product Description
Photo Recording
Photo resolution:8MP;5MP;3MP
Image format:Full Screen,Wide Screen;Programmable
File format: JPEG
Capture number (Muti-Shot):1-3 Programmable
Photo stamp: Time, Day,Moon,Temperature;
Camera name:Input
Capture mode: Color by day, black and white by night
Video Recording Video resolution: 640X480; 320X240
File format: AVI
Video length: 5~60sec;Programmable
Audio video: YES
Lens
f=7.45mm, FOV=55°; F/NO:2.8; Horizonal View Angel =42°
Auto IR-Cut-Remove (at night) Viewing LCD display: 2.4"Color Display
TV output computer output:USB2.0,Net cable connectTime System Shutter speed: 1/10~1/2000 Second
Self time mode: PIR Auto
Trigger time: <0.8 Second
Trigger interval:1~59 sec.;1~60min; Programmable
Timed scan: 2XNight time llumination System IR-Flash mode: Automatic Synchronization
IR-Flash range: 20-25M
IR-LED control: High,Medium,Low;Programmable
LED: Dark glass/ No Glow /940nm LEDsDetection System Motion sensor: PIR
PIR sensitivity: High/Normal/Low/Auto
Detection range:20-25M Field of viewing angle: 55°
Indicating: Dual color indicating light,
Photosensitive Resistance,
Updating Light;Power Supply Alkaline or lithium Batteries: Alkaline recommended
Alkaline battery Pack:8xAA recommended;
4xAA as emergency power
External jack: 6V jack
Connectivity: USB2.0, SD Card Holder;
TV Out(NTSC/PAL);DC External
Solar panel: 6V
Power consumption: <200mA (+600mA when IR-LED lighted)
Stand-by current: <0.28mA(<7mAh/day)Memory storage External memory: SD/MMC Card (Max.32GB)
Internal memory:32M
DDR:512M
Image recycle: YES| CARD SIZE | Estimated Card Capacity |
| No.of images(jpg) | Length of video(avi) |
| 3MP | 5MP | 320X240 | 640X480 |
| 4GB | 8000 | 3600 | 240min | 120min |
| 8GB | 16000 | 7200 | 480min | 240min |
| 16GB | 32000 | 14400 | 960min | 480min |
| 32GB | 64000 | 28800 | 1920min | 960min |
