Product Specifications
| Prod Model: |
SV-MIP150-WDR |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
1. Waterproof IP Camera, Network Camera (SV-MIP150)
2. H. 264 2.0 Megapixel IP camera
3. Support Two Way Audio
4. WiFi transimssion
5. Support SD card
Feature
1. 1/3'' Progressive Scan CMOS sensor
2. Low Illumination 0.05 lux and 0 lux when IR on.
3. High Resolution 1280*720P. Optional video resolution of D1 640*480 and CIF 320*240.
4. 4mm, 6mm, 8mm lens available.
5. Day and night surveillance. 48*F5 LEDs makes 30m IR view distance
6. H. 264 baseline profile @Level 3.0 realizes transmission of high definition video over low network bandwidth easily
7. Real time transmission of 30FPS
8. Dual H. 264 stream, resolution, frame rate and bit rate adjustable.
9. Multiple network protocol- TCP/IP, UDP, HTTP, FPT, SMTP, DNS, ARP, ICMP, POP3, NTP and RTSP
10. Remote view and management by IE and client software (CMS)
11. Various recording modes motion detection recording, alarm recording, schedule recording and manual recording
12. Support built-in 802.3af Compliant POE
13. Support 2-way audio with external microphone and speaker
14. ONVIF compliant. Compatible with Milestone, Axxon and Nuuo, etc.
15. Support iPhone and iPad mobile view.
16. Support WDR POE functions
Technical Specification:
|
Item no. |
SV-MIP150-WDR |
Image Sensor |
1/2.5" 2.0 Megapixel Progressive Scan CMOS sensor |
Lens |
4mm,6mm,8mm |
LEDs & IR distance |
2 LEDs array, 40-45m IR view |
Min. Illumination |
1.76V/ Lux -sec; 0 Lux@IR on |
CPU |
TI TMS320DM368 |
OS |
Embedded RTOS design, dual core DSP 32bit. |
Video Codec |
H.264 |
Analog Video Output |
1CH BNC output, support CVBS standard |
Video Resolution |
Main stream: 5MP@10FPS; 3MP@15FPS; 1080P, 1200P, 1024P, 960P, 720P@25FPS |
Sub stream: 640*360, 480*270, 352*192@25FPS |
Video Frame Rate |
25FPS , support adjustable 1-25fps |
Streaming Level |
2 adjustable |
Bit Rate |
50k-8Mbps |
Audio compression |
AAC standard, Support 2-way audio and Synchronous AV |
Audio input |
2Vp-p, 1Vms, support pickups input (only for active audio) |
Audio output |
16Vms, 30mw, support earphone or power amplifier |
Network Port |
10-100M Ethernet RJ45 port |
USB Port |
1 USB port, support max.64G U disk recording , SD card |
Network Protocol |
TCP/IP/HTTP/RTSP/FTP/PPPOE/DDNS/NTP/UPnP |
PTZ Control |
RS422/RS485 Serial Port. , support multiple PTZ control protocol, such as PELCO ( P) / PELCO (D) / MOLYN (P) / SANTA (P) |
PoE |
Support built-in 802.3af Compliant POE |
SD card |
Optional |
Software |
Free Client software and charged Intelligent Video CMS software |
IVS software support mobile phone view. Symbian , Android and I Phone mobile. |
ONVIF |
ONVIF 2.0 compliant |
Working Temperature |
temperature -10 ~ +50 C |
Power input |
DC 12V +5% |
