Shenzhen Vteam Co., Ltd. >> HD Video Effect for Stage Show Igrid Screens

HD Video Effect for Stage Show Igrid Screens

Name: HD Video Effect for Stage Show Igrid Screens
Brand: China-Manufacturer-Directory.com
SKU: 738498445
Availability: InStock
Rating: 4.4 (93 reviews)

Supplier:	Shenzhen Vteam Co., Ltd.
Price:	US $ 296-665piece
Min Order:	6piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	iGrid
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brightness:	5000 Nits/3500nits/1500 Nits
Viewing Distance:	More Than 15m, 19m, 25m, 38m
Refresh Rate:	1800Hz/2400Hz/3600Hz/4800Hz
Cabinet Size:	600 X 600 X 85mm or 900 X 60 X 85mm
Viewing Angle:	140/140
Gray Scale:	>16bit
Input Voltage:	AC 220V±10% 50/60Hz
Working Environment:	Temperature-20~+50degree, Humidity10~95% Rh
Life Time:	> 50, 000 Hours
Tube Chip Color:	Full Color
IP Rating:	IP65
Display Function:	Video Display
Pixel Configuration:	RGB 3in1 SMD3535
Pixel Pitch:	15mm/18.75mm/25mm/37.5mm
Pixel Density:	4444sqm/2844sqm/1600sqm/711sqm
Average Power Consumption:	900W/Sqm, 700W/Sqm, 400W/Sqm, 200W/Sqm

Product Description

IGird is a LED strip curtain display with light and thin body. Transparent design, the easy, firm and correct installation can be done with one people operation. The special design of electronic elements inside makes iGrid more waterproof and shockproof. SMD 3in1 LEDs and static constant drive, high brightness, high refresh rate, high gray scale all make iGrid LED curtain a number one choice for indoor and outdoor large-scale stage design.

Main Advantages:
1. Light, suitable for touring shows, convenient in transporting and jointing.
2. Strong and nice-looking structure.
3. Two size with 900X600X85mm and 600X600X85mm for different demands.
4. IP 65 for temporary outdoor use, makes it possible to work no matter in rainy days.
5. Can achieve any arc-shaped with ± 10° .
6. Easy and correct installation can be done with one person tool free operation.
7. High transparency for light, smoke and sound on stage going through.
8. Personalized operation interface, power and signal lights for debugging.

Item	iGrid 15	iGrid 18.75	iGrid 25	iGrid 37.5
Pixel Pitch	15mm	18.75mm	25mm	37.5mm
Pixel Density/sqm	4444	2844	1600	711
Pixel Matrix (600X600mm)	40(H)×40(V)	32(H)×32(V)	24(H)×24(V)	16(H)×16(V)
Pixel Matrix (600X900mm)	40(H)×60(V)	32(H)×48(V)	24(H)×36(V)	16(H)×24(V)
Weight(600X600mm)	8KG	7.5KG	7KG	6.5KG
Weight(600X900mm)	13KG	12KG	11KG	10KG
Brightness	5000 Nit	≥5000 Nit	≥3500 Nit	≥1500 Nit
Viewing Distance	≥15m	≥19m	≥25m	≥38m
Max. Power consumption	900 W/sqm	700 W/sqm	400 W/sqm	200 W/sqm
Ave. Power consumption	480 W/sqm	400 W/sqm	220 W/sqm	110 W/sqm
Refresh Rate	1800HZ	2400HZ	3600HZ	4800HZ
Panel Size	600×600×85mm or 900×600×85mm
Led Type	RGB 3in1 SMD3535
Gray Scale	16bit
Protection Level	In Front IP65, At Back IP65
Viewing Angle	140°/140°
Input voltage	AC 220V±10% 50/60HZ
Working Environment	Temperature-20~+50degree,Humidity10~95% RH
Lifetime	> 50,000hours

SHENZHEN VTEAM Co., Ltd. is a professional ODM LED Screen manufacturer in Shenzhen, China, specialized in creative indoor and outdoor LED screen with experienced R&D team who has been working in LED display field for more than 8 years.

VTEAM screen is popular with the features of light weight, ultra-thin cabinet, transparent structures and widely-used in the application of TV Station, studios, auto shows, music concerts, clubs, discos, building facade, outdoor decorative lighting projects, exhibitions, celebrations etc.

As one of leaders of LED Screen suppliers in China, All products carry CE RoHS certification, with perfect designed products, customized solution, superior product and service guarantee, VTEAM has been highly praised by domestic and overseas customers, we have been shipping qualified products and services to more than 100 countries and regions all over the world, such as in the USA, Russia, Germany, Sweden, France, Netherland, Spain, Canada, Brazil, Mexico etc. The most notable of those successful projects is that we have done the creative "Giant Football" for the opening&closing ceremony of 2014 Brazil FIFA WORLD CUP!

VTEAM Mission: To create value and profit for customers!

VTEAM Vision: Being creative concept pioneer!
