HDMI Matrix

Product Specifications

Prod Model:	HTM0404AN
Markets:	North America,South America,Eastern Europe,Southeast Asia,Mid East,Western Europe

Product Description

Package Includes:

1x HTM0404ANR
1x IR Remote control
1x 5V Universal Power Supply
1x User's Manual

Features
Support true matrix outputs,connecting 4 HDMI inputs and 4 HDMI outputs
Support deep color up to 12bit per channel
Support HDMI digital audio format:LPCM/Dolby-AC3/DTS7.1/DSD/Dolby true HD/DTS-HD master Audio.
Remote control;manual operated and automatic selection function
Remote control function via Rs232
Favourite input source setting.
Perfect compatibility with any HDMI applications.
Great working stability.
Power Adapter included , plug and play.

SMART FUNCTION INTRODUCTION
1.Sense the input source ports automatically ,and bypass the port without signal .
2.Remember the active input source port(s) while pressing "RESET" on the remote control, and select this input source port automatically when restart.
SPECIFICATIONS
Support 3DTV
Support resolution: 1080P/1080i/720P/576P/480P/576i/480i
Support audio format: LPCM, Dolby-AC3,DTS7.1,DSD/Dolby TrueHD/ DTS-HD Master Audio.
Support deep color up to 36bit
Support data transfer bitrates up to 2.25Gbps/per chennel
Tmds clock frequency range:25~225Mhz
Support input video signal volts:0.5Vp-p
Support DDCsignal volts:5Vp-p
Power supply:DC5V/4A
Power adapter format : Input AC(50HZ.60HZ) A100V-240V;  Output DC5V/4A
HDMI output cable distance : ≤15m(if need longer,amplifier is needed )
Operating temperature range : -5 to +35oC(-41 to +95oF)
Operating humidity range : 5 to 90 % RH (no condensation)
