Product Specifications
| Prod Model: |
CT6110G |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Overview
HDMI to SD/HD/3G-SDI Converter is mainly used in converting one channel high-definition multimedia interface (HDMI) signal to high-definition serial digital component interface (HD-SDI) signal. The device integrates SDI transmitter and HDMI demodulator, and after separate and convert HDMI audio signal, then embed to HD-SDI signal, and achieve the sound and image synchronization transmission. The resolutions of HDMI or SDI would be forced by the console.
Features
The resolutions of HDMI or SDI would be forced by the console
One piece of 75Ω Coax. Cable can substitute HDMI cable to achieve long distance transmission.
Transmission distance can be up to 120 meters (400 feet Max) for 1080p using RG-6U Cable.
Maintains highest HDMI single link video resolution 1080P@30Hz/60Hz.
Support digital video formats in Deep Color Mode at up to 12bits/color.
Support full HDMI audio and video.
Support external audio embed into SDI signal synchronously
Power supply and SDI signal format indicator
Specifications
Input Interface
2xHDMI
Audio Input Interface
1xAudio
Frequency Bandwidth
225MHz/ up to standard with HDCP: HDMI 1.3
Support Input Format
480i, 576i, 720p@50/60, 1080i@50/60, 1080p@24/25/30,
1080p50/60
SDI Out Interface
2x BNC(SD-SDI/HD-SDI/3G-SDI)
SDI Signal Range
0.8Vp-p
SDI Impedance
75ohms
SDI Coupling Type
AC Coupling
SDI signal jitter (typical value)
SD-SDI≤ 0.1 UI HD-SDI≤ 0.2UI 3G-SDI≤ 0.4 UI
Manual Control Output Format
1080p60/50/30/25 1080i60/50 720p60/50/30
Max. Output Coax Length
Belden1694A
SD-SDI 400m/1300ft; HD-SDI 200m/600ft; 3G-SDI140m/450ft
Power Supply
12VDC, 1Aw/LockingPower Connector
Power Consumption
3~6 Watts
Operating Temperature
-10° C~60° C/14° F~140° F
Storage Temperature
-30° C~70° C/-22° F~158° F
Relative Humidity
20~90%RH(Non-condensation)
Dimension
158× 120× 36mm/6.22× 4.72× 1.42in
Weight
300g
