Product Specifications
| Prod Model: |
ADS158 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wire Diameter: |
0.4mm to 2.1mm |
| Material: |
Galvanized Iron Wire |
| Hole Shape: |
Hexagonal |
| Mesh Size: |
3/8 Inch |
| Surface Treatment: |
Galvanized |
| Weave Technique: |
Plain Weave |
| Application: |
Cages |
| Color: |
Green |
| Type: |
Wire Mesh |
| Certification: |
SGS |
| Condition: |
New |
Product Description
Hexagonal Shape Wire Mesh/Hexagoanl Wire Netting
material:galvanized iron wire, black iron wire, 304 310 316 321 stainless steel wire, brass, copper wire ,other materials on request
Certification: ISO9001:2008 and SGS
Specification:
Hexagonal wire mesh
Mesh:10mm to 100mm
Wire:0.4mm to 2.1mm
Roll: 0.5-2m width x 30/50/100m length
galvanized, pvc coated
(special specification can do)
surface treatment:
1) electro galvanized before weaving
2) electro galvanized after weaving
3) hot dipped galvanized before weaving
4) hot dipped galvanized after weaving
5) pvc/plastic coated before weaving
6) pvc/plastic coated after
Feature:
1) corrosion- resistant, rust-resistant.
2) oxidation resistant, good tensile strength.
3) uniform mesh size, flat and even mesh surface, weave tightly.
4) galvanized /pvc coated for longer life, low costs
5) easy to handle and cut.
Application:
1) Structural purposes , Heat insulation (ceilings, boilers..)
2) Pipe wrapping(petrolium) ,Isolation purposes ,
3) Indicator & protection for underground cables and pipes , Windows Protection
4) Light fencing applications ,Fishing ,Poultry farms ,Sugar industry
5) Rubber industry , rockwool blanket industry.
6) Poultry & animal housing, Crop protection. Fruit cages, Garden Protection, Rabbit Control ,Stucco in construction, reinforcement in road.
Packaging:
1) shrink film+ label (customer's logo is ok )
2) water-proof paper+ shrink film+ label
3) water-proof paper+ shrink film+label, then incardboard carton
4) water-proof paper+ shrink film+label, then in pallet.
We can pack as customers' specific requirements.
Galvanized hexagonal wire netting |
mesh | Min. Gal.v.
G/SQ.M |
Width | Wire Gauge (Diameter)
BWG |
Inch | mm | Tolerance(mm) |
| 3/8" | 10mm | ±1.0 | 0.7mm - 145 | 2' - 1M | 27, 26, 25, 24, 23 |
| 1/2" | 13mm | ±1.5 | 0.7mm - 95 | 2' - 2M | 25, 24, 23, 22, 21 |
| 5/8" | 16mm | ±2.0 | 0.7mm - 70 | 2' - 2M | 27, 26, 25, 24, 23, 22 |
| 3/4" | 20mm | ±3.0 | 0.7mm - 55 | 2' - 2M | 25, 24, 23, 22, 21, 20, 19 |
| 1" | 25mm | ±3.0 | 0.9mm - 55 | 1' - 2M | 25, 24, 23, 22, 21, 20, 19, 18 |
| 1-1/4" | 31mm | ±4.0 | 0.9mm - 40 | 1' - 2M | 23, 22, 21, 20, 19, 18 |
| 1-1/2" | 40mm | ±5.0 | 1.0mm - 45 | 1' - 2M | 23, 22, 21, 20, 19, 18 |
| 2" | 50mm | ±6.0 | 1.2mm - 40 | 1' - 2M | 23, 22, 21, 20, 19, 18 |
| 2-1/2" | 65mm | ±7.0 | 1.0mm - 30 | 1' - 2M | 21, 20, 19, 18 |
| 3" | 75mm | ±8.0 | 1.4mm - 30 | 2' - 2M | 20, 19, 18, 17 |
| 4" | 100mm | ±8.0 | 1.6mm - 30 | 2' - 2M | 19, 18, 17, 16 |
