Product Specifications
| Prod Model: |
YND-M-HMC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Roll Size: |
3'*100',4'*100',Ect |
| Mesh Size: |
1/2'' 3/4'' 1'' 2'' 3'' 4'' as Your Require |
| Characteristics: |
Corrosion Resisting,Oxidation Resisting |
| Zinc Coat: |
10-12/35-50G/M2,Can Reach 300G/M2 |
| Surface Treatment: |
PVC Coated |
| Material: |
Stainless Steel Wire |
| Application: |
Construction Wire Mesh |
| Weave Method: |
Twist |
| Weave Technique: |
Plain Weave |
Product Description
HEXAGONAL WIRE MESH
Material: High quality low carbon steel wire, stainless steel wire.
Weaving and characteristcs: Reverse twisted, normal twisted, bidirectional twists galvanized after weaving or galvanizing. Before weaving, it is divided to electroplate galvanized. Hot-dipped, plastic-coating, stainless steel. PVC coating, etc. It has the characteristics of corrosion resisting and oxidation-resisting.
Uses: Used in building, oil, chemical industry, breed, plant protect. Food processings reinforce, guard and heat-keeping for example, make net cast, ston cage, insulated net, wall boiler cover, poultry fence, chicken wire mesh, rabbit fence, ect.
Hexagonal mesh is firm in structure and has flat surface. It is extensively used in building as reinforcement of the roof and floor. It is also used as fence for poultry cage, fish garden and children playground.
Hexagonal Wire Netting can be made into different types according to the netting treatment, processing, material used or according to the application.
We have commonly three processing methods to make products of different features: Straight twisted, reverse twisted and double twisted strengthened.
Hexagonal wire mesh can be made of galvanized iron wire, electro galvanized or hot dipped zinc plated.
Galvanized Hexagonal Wire Netting Application: As fences, chicken wire, stucco netting, or made into gabions or baskets for protection
Assortments available:
· Hot-dipped galvanized after weaving
· Hot-dipped galvanized before weaving
· Electro galvanized after weaving
· Electro galvanized before weaving
· Hex. Wire mesh, PVC-coated
· Hex. Wire mesh in normal twist.
· Hex. Wire mesh in reverse twist.
|
Galvanized Hexagonal Wire Netting |
|
Mesh |
Min. Gal. v. G/SQ. M
|
Width |
Wire Gauge (Diameter) BWG
|
Inch
|
mm |
Tolerance(mm) |
|
3/8" |
10mm |
± 1.0 |
0.7mm - 145 |
2' - 1M |
27, 26, 25, 24, 23 |
|
1/2" |
13mm |
± 1.5 |
0.7mm - 95 |
2' - 2M |
25, 24, 23, 22, 21 |
|
5/8" |
16mm |
± 2.0 |
0.7mm - 70 |
2' - 2M |
27, 26, 25, 24, 23, 22 |
|
3/4" |
20mm |
± 3.0 |
0.7mm - 55 |
2' - 2M |
25, 24, 23, 22, 21, 20, 19 |
|
1" |
25mm |
± 3.0 |
0.9mm - 55 |
1' - 2M |
25, 24, 23, 22, 21, 20, 19, 18 |
|
1-1/4" |
31mm |
± 4.0 |
0.9mm - 40 |
1' - 2M |
23, 22, 21, 20, 19, 18 |
|
1-1/2" |
40mm |
± 5.0 |
1.0mm - 45 |
1' - 2M |
23, 22, 21, 20, 19, 18 |
|
2" |
50mm |
± 6.0 |
1.2mm - 40 |
1' - 2M |
23, 22, 21, 20, 19, 18 |
|
2-1/2" |
65mm |
± 7.0 |
1.0mm - 30 |
1' - 2M |
21, 20, 19, 18 |
|
3" |
75mm |
± 8.0 |
1.4mm - 30 |
2' - 2M |
20, 19, 18, 17 |
|
4" |
100mm |
± 8.0 |
1.6mm - 30 |
2' - 2M |
19, 18, 17, 16 |
Note:
1. ) The above tolerance comply with standard EN10223-2: 1997;
2. ) Minimum Galvanization is only for typical wire diameter as stipulated separately in the column for your reference; Also it is only for hot dipped Galvanized Netting.
|
PVC Coated Hexagonal Wire Netting |
|
Mesh |
Wire Gauge (MM) |
Width |
|
Inch |
MM |
- |
- |
|
1/2" |
13mm |
0.6mm - 1.0mm |
2' - 2M |
|
3/4" |
19mm |
0.6mm - 1.0mm |
2' - 2M |
|
1" |
25mm |
0.7mm - 1.3mm |
1' - 2M |
|
1-1/4" |
30mm |
0.85mm - 1.3mm |
1' - 2M |
|
1-1/2" |
40mm |
0.85mm - 1.4mm |
1' - 2M |
|
2" |
50mm |
1.0mm - 1.4mm |
1' - 2M |
|
We also offer other specifications you need |
