Product Specifications
| Prod Model: |
VM-1033 |
| Voltage: |
AC 220V |
| Function: |
Amplifier Combined |
| Tube Type: |
Transistor Amplifier |
| Element Number: |
Monoamplifier |
Product Description
It widely used in schools, malls, hotels, factories, conference rooms, gardens, etc.
|
Model |
VM-1033 |
|
Type |
Two-way micron line array module |
|
Frequency Response |
80-20KHZ(± 3dB) |
|
Input Mode |
100V |
|
Rated Power |
300W AES, 120W peak |
|
Sensitivity |
88dB |
|
Max. SPL |
100dB continuous, 106dB peak |
|
Dispersion(-6dB) |
90° horizontal, 10° vertical |
|
Fractonal Frequency |
2.5KHZ passive |
|
Speaker |
2X3" LF Drives + 1X1" Horn tweeter |
|
Dimensions |
25cmX11.5cmX16.3cm |
|
Weight |
2.7Kg |
|
Installation accessories |
A set of fixed revolving adjust accessory |
|
Dimensions of Carton |
4 PCS / 50.5X 35X31cm |
|
Model |
VM-4033/VM-4033Het |
VM-8033/VM-8033Het |
VM-16033/VM-16033Het |
|
Amount of Modules |
4 |
8 |
16 |
|
Sensitivity |
95dB |
101dB |
107dB |
|
Input Mode |
120W AES |
240W AES |
480W AES |
|
Rated Power |
480W peak |
960W peak |
1920W peak |
|
Max SPL |
115dB |
121dB |
127dB |
|
Max Cover Distance |
8-12M |
15-25M |
25-40M |
|
Array Length |
47cm |
94cm |
188cm |
|
Array Weight |
11.7Kg |
23.4Kg |
47Kg |
|
Installation accessories |
A set of fixed adjust accessory |
1. A set of fixed adjust accessory, 2. A set of fixed connect |
We Zhongshan VBO Hardware&Electrical Equipment Co., Ltd specialize in manufacturing PA System, professional stage sound system and hardware accessories. We are strict with quality of product, and the selling price is competitive in the marketing. Our products get the good feedback all along from customers, and good sale to overseas. We got the ISO9001, CCC, CE, ROHS certificate etc.
