Supplier: | Glorytek Industry (Beijing) Co., Ltd. |
---|---|
Price: | US $ 50/Piece |
Min Order: | 1/Piece |
Quantity:: | |
Trade Terms: | FOB,CFR,CIF |
![]() |
Prod Model: | GL360-165 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Number Of Air Hole: | 2 |
Dia: | 165-170 |
Weight: | 26.5 |
Gauge Button: | 8×16 |
Type: | Gl360-165 |
Glorytek Industry (Beijing)Co.,Ltd., located inBeijing,China, is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for decades. We are supported and assisted by a highly experienced team of designers and engineers that enable us to complete all the assigned projects successfully as per the specified requirement from our clients.
Our products are widely used in the scope of mining, water well drilling and exploration, anchor grouting project, side slope protection engineering, oil and gas engineering,underwater rock drilling & blasting operations of seaport channel, hydropower project, national defense projects ect.
Type and Technical Specification of bits for medium & high pressure DTH Hammers
Type | Number of Air hole | DIa.(mm) | Weight(kg) | Gauge Button | Front Button | Matching DTH Hammer |
GL4.5-115 | 2 | 115-118 | 6.4 | 7×14 | 6×12 | GL4.5 |
GL4.5-120 | 2 | 120-123 | 7 | 7×14 | 6×12 | |
GL4.5-130 | 2 | 130-133 | 8 | 7×14 | 6×12 | |
GL4.5-140 | 2 | 140-143 | 8.2 | 7×14 | 6×12 | |
GL4.5-150 | 2 | 150-153 | 9 | 7×14 | 6×12 | |
GL330-85 | 2 | 82-85 | 3.4 | 6×14 | 3×12 | GL330 |
GL335-90 | 2 | 90-93 | 4.6 | 6×14 | 7×12 | GL335 |
GL340-105 | 2 | 105-108 | 7.7 | 8×14 | 7×13 | GL340 GL345 GL345K |
GL340-115 | 2 | 115-118 | 8 | 8×14 | 7×13 | |
GL340-130 | 2 | 130-133 | 10.5 | 8×14 | 8×13 | |
GL350-130 | 2 | 130-133 | 17 | 7×16 | 7×14 | GL350 GL355 GL355K |
GL350-140 | 2 | 140-143 | 18 | 7×16 | 7×14 | |
GL350-152 | 2 | 152-155 | 19 | 6×16 | 6×14 | |
GL360-152 | 2 | 152-155 | 25 | 8×16 | 11×14 | GL360 |
GL360-165 | 2 | 165-170 | 26.5 | 8×16 | 11×16 | |
GL360-178 | 2 | 178-183 | 28.6 | 8×16 | 11×16 | |
GL360-194 | 3 | 194-197 | 30 | 9×16 | 12×16 | |
GL360-203 | 3 | 203-206 | 32 | 9×16 | 13×16 | |
GL360-216 | 3 | 216-219 | 35 | 9×16 | 13×16 | |
GL360-230 | 3 | 230-233 | 37 | 12×16 | 16×16 | |
GL360-254 | 3 | 254-257 | 43 | 12×16 | 16×16 | |
GL360-305 | 3 | 305-308 | 57 | 14×18 | 26×16 | |
GL380-203 | 2 | 203-206 | 48 | 8×18 | 10×16 | GL380 |
GL380-216 | 3 | 216-219 | 50 | 9×18 | 13×16 | |
GL380-230 | 3 | 230-233 | 53 | 9×18 | 17×16 | |
GL380-254 | 3 | 254-257 | 58 | 9×18 | 16×16 | |
GL380-310 | 3 | 310-313 | 71 | 12×18 | 15×16 | |
GL380-350 | 4 | 350-353 | 80 | 16×18 | 36×16 | |
GL3120-302 | 3 | 302-305 | 176 | 12×18 | ×18 | GL3120 |
GL3120-311 | 3 | 311-314 | 177 | 12×18 | ×18 | |
GL3120-330 | 3 | 330-333 | 186 | 12×18 | ×18 | |
GL3120-357 | 3 | 357-360 | 196 | 18×18 | ×18 | |
GL3120-381 | 3 | 381-384 | 205 | 18×18 | ×18 | |
GL3120-444 | 3 | 444-447 | 230 | 18×18 | ×18 | |
GL3120-483 | 3 | 483-486 | 285 | 18×18 | ×18 | |
GL3120-508 | 3 | 508-511 | 311 | 18×18 | ×18 |
