Energy comparing with 0.7-0.8Mpa air compressor.
Its advantages depict from following aspects:
When 0.2--0.5Mpa is your gas pressure,
Selection of General 0.7Mpa air compressor will cause great waste of electricity. Choosing low-voltage screw air compressor can significantly increases gas production under the same power of motor, accordingly, -----you can save 20-50%.
If you purchased the 0.7Mpa machine, but the actual working pressure is 0.5Mpa, it is often the case: Screw hosts firstly compressed air to 0.7Mpa, then through pressure reducing valve reduces the air pressure to 0.5Mpa. In other words, you are using 0.5Mpa, you inherit the power of 0.7Mpa.
Air displacement can also be proved:
A single screw air compressor, 132kW, its discharge capacity should be 24m3/min. Using KHE132kW, 0.5Mpa screw air compressor, it exhausts over the amount of 37m3/min, which allows you to recoup your investment less than a year in this way of saving energy.
According to the user's use of pressure, automatically adjust compression ratios, 0.2~0.5Mpa exhaust ing pressure range, can keep the best power (energy efficiency).
Oil pump forced lubrication
Ensure there's plenty of oil, best oil and gas mixing ratio under low exhausting pressure.
|
model |
discharge pressure |
discharge volume |
power of motor |
noise dB(A) |
dimension |
|
MPa |
m3/min |
kW |
mm |
|
KHE30-5 |
0.5 |
6.55 |
30 |
69 |
1680×1260×1350 |
|
KHE 45-5 |
0.5 |
10.7 |
45 |
70 |
2220×1410×1720 |
|
KHE 75-5 |
0.5 |
17.49 |
75 |
72 |
2560×1490×1820 |
|
KHE 90-5 |
0.5 |
22.75 |
90 |
72 |
3110×1690×2200 |
|
KHE 110-5 |
0.5 |
25.44 |
110 |
73 |
3110×1690×2200 |
|
KHE 132-5 |
0.5 |
30 |
132 |
75 |
3660×1760×2190 |
|
KHE 160-5 |
0.5 |
39.83 |
160 |
75 |
3660×1760×2190 |
|
KHE 250-5 |
0.5 |
55.73 |
250 |
78 |
4160×2160×2300 |
Our goal is to deliver smart and reliable manufacturing, installation and maintenance of compressed air solutions for our customer needs. We have gained our position as a leader in the compressor world by working diligently in improving our products, techniques and customer service in every scale.
With manufacturing facilities in China and a worldwide distribution network, BEST-PAL serves customers in every corner of the globe. BEST-PAL factory in China is ISO 9001: 2008 certified to assure the highest quality standards.
D-TECH Air Compressors
The Energy-Saving D-Tech Patented Profile Airend Larger, slower-running airends are more efficient and deliver more compressed air for the same input power. BEST-PAL Patented Profile Airends are optimized and designed to operate at the lowest possible speeds. Every BEST-PAL rotary screw compressor is equipped with a highly efficient airend and will quickly pay back for itself through power cost savings.
Time Proven Reliable Airend
Used in compressors worldwide, BEST-PAL airends have proven to be the market leader in both reliability and efficiency.
Precision machined rotors.
Highest quality tapered roller bearings.
All coolant flow paths are integral to the cast housing, eliminating potential leak paths.
Ideal wherever budgets are limited, but the need for performance is not.
Premium Efficiency And Performance
BEST-PAL's premium efficiency compressors deliver reliability through our unique airends, reknowed for trouble-free operation and low energy consumption. Efficiency and durability through low compression ratio in each stage.
