Product Specifications
Product Description
The HFP-800 works with LPS-3 (Auxiliary Power Supply) and RB-3 (Adjustable Resistance Ballast) to be an IEC Standard Test System which used to test the Frequency Fluorescent Lamp such as T5 Tube, please click here to learn the more details
Features:
？ Program control output voltage and easy operation
？ Set data easily with a memory chip, unnecessary to set for many times
？ Display on four windows, each window shows one parameter independently
？ Application for all kinds fluorescent lamps such as 50Hz/60Hz T8/T12 tube or 25KHz T5 Tube
？ It is according to double-ended fluorescent lamps adoptting the IEC 60081 (GB/T10682) and the single-ended fluorescent lamps adoptting the IEC 60901 (GB/T17262)
Specifications:
？ Range for output voltage: 0~600V (Adjustable)
？ Range for output current: 0~0.600A
？ Range for output frequency: 25KHz
？ Range for output capacity: 0~300W (Special request to 500W)
？ Range for Voltage stability: 0.5%/30 minutes
？ Range for frequency stability: 0.02%
Lisun Electronics Inc was found by Lisun Group in 2003. We have salesservice offices in Hong Kong and Shanghai. In 2012, we built a high level products show room lab center in Shanghai, Lisun Group has set up a new manufactory in China to research and develop the world high-technology CFL LED Test Instruments. Its quality system has been strictly certified by ISO9001: 2008. The Lisun Group Products have been authenticated by the third party lab and were awarded by CE certificate. As a CIE Supportive Membership, all of the test instruments produced by Lisun Group were designed according to CIE Standards
Our main products are Goniophotometer, Spectrophotometer, Integrating Sphere, Photometer and Colorimeter, LED Test Instruments, CFL Test Instruments, EMC Testing, Electronic Ballast Tester, Equipments For Testing Electronic Components, Electrical Safty Testing, Environmental Testing, AC and DC Power Supply and etc.
Lisun Group`s Products have been sold to more than 50 countries and regions in Europe, America, Australia, Africa and Asia, Its quality was well accepted by many of world famous companies such as TUV, SGS, UL, GE, Philips, Sharp, OSRAM, Sony and so on. Lisun Group wins thousands of customers` trust with motto"Right Product, Right Price and Right Service". We will continue presenting more and more high quality products to our customers in future.
