1.Application
Our machine are mainly used on distribution box .Advertising sign ,housing decoration ,iron art garden ,electric appliances and cutting of plate material etc .
2.Technical parameters
| Input voltage | 3-phase 380v /2-phase 220v |
| Power | 8.5kw |
| Frequency of power supply | 50hz |
| Plasma current | 45a-100a |
| Manufacture thickness | 0.3mm-10mm |
| Working area | 1300*2500mm |
| Working table | Serrated table |
| Transmission model | Rack gear |
| Guide way | Square rail |
| Cutting speed | 10m/min |
| Cutting thickness | Depend on current of plasma power source |
| Process precision | Within 0.1mm |
| File transfer mode | USB interface |
| Power supply | Huayuan power or according to your requirements |
| Software | Fastcam /artcam /type3 |
| Working mode | Non-contact arc |
| Cnc control system | DSP |
3.Characteristics
1.The fastest cutting speed reaching 10m/min,and precision within 0.1mm.
2.The whole macine made by the way of rivet welding ,avoiding body deformation
3.Cutting mouth little and tidy without any dropouts ,and avoiding second trimmming .
4.Applied for metal sheet ,aluminum sheet ,galvanized sheet .Stainless sheet ,titamium sheet and so on
5.Cnc system configure high ,performance stable ,automatic arc striking and success of striking arc reaching 99%.
6.Plasma power can select usa hypertherm and power made in China
7.Surporting ARTCUT ,CAXA ,ARTCAM ,TYPE3,etc ,and also can be converted into .Bmp ,.Dxf,.Cdr,.Etc,file types .
8.Laser module positioning ,easy to operate and embodying the humaniztion .
9.Fast clamp position avoiding sheet moving ,greatly reducing client's cost
10.Cooling gauge setting ,greatly improving machine life and ensuring machine working in good condition
