High Precision Leaded Resistor

Name: High Precision Leaded Resistor
Brand: China-Manufacturer-Directory.com
SKU: 706472822
Availability: InStock
Rating: 4.5 (36 reviews)

Supplier:	Shenzhen Ellon Electro-Mechanics Co., Ltd.
Price:	US $ 0.002-0.23/Piece
Min Order:	30000/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	MFD0727BACV1001
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Resistance:	Fixed Resistor
Installation:	SMD Resistor
Material:	Metal Film Resistor
Package Type:	Surface Mount
Type:	Fuse Resistor
Brand:	Ellon

Product Description

Very tight tolerance down to ±0.02%
Extremely low TCR down to ±5PPM/°C

Add to	Series	Size	Power	Tolerance	Resistance	TCR/PPM
	MFD0727	0727	1/4W	±0.02%, ±0.05%,±0.1%	10Ω~1MΩ	±5~ ±100
	MFD1040	1040	1/2W	±0.02%, ±0.05%,±0.1%	10Ω~1MΩ	±5~ ±100

Add to	Series	Size	Power	Tolerance	Resistance	TCR/PPM
	MFR0318	0318	1/8W~2/5W	±0.05%,±0.1%~±1%	0.1Ω~10MΩ	±5/10/15/25/50/100
	MFR0623	0623	1/4W~3/5W	±0.05%,±0.1%~±1%	0.1Ω~10MΩ	±5/10/15/25/50/100
	MFR0932	0932	1/2W~1W	±0.05%,±0.1%~±1%	0.1Ω~10MΩ	±5/10/15/25/50/100
	MFR1145	1145	1W~2W	±0.05%,±0.1%~±1%	0.1Ω~10MΩ	±5/10/15/25/50/100
	MFR1150	1150	2W~3W	±0.05%,±0.1%~±1%	0.1Ω~10MΩ	±5/10/15/25/50/100

Add to	Series	Size	Power	Tolerance	Resistance	TCR/PPM
	LR06	1206	1W	±1%, ±3%,±5%	1mΩ~10mΩ	±50
	LR10	2010	1.5W	±1%, ±3%,±5%	0.5mΩ~10mΩ	±50~ ±150
	LR12 (B)	2512	1W,2W	±1%, ±3%,±5%	0.5mΩ~10mΩ	±50~ ±150
	LR12 (G)	2512	1W,2W,3W	±1%, ±3%,±5%	0.5mΩ~15mΩ	±50~±100

Add to	Series	Size	Power	Tolerance	Resistance	TCR/PPM
	RS-02	0402	1/16W, 1/8W	±1%,±5%	50mΩ~1Ω	±500~ ±800
	RS-03	0603	1/10W~1/8W	±1%,±5%	20mΩ~1Ω	±500~ ±1200
	RS-05	0805	1/8W, 1/4W	±1%,±5%	10mΩ~1Ω	±500~ ±1500
	RS-06	1206	1/4W, 1/2W	±1%,±5%	10mΩ~1Ω	±500~ ±1500
	RS-0A	2010	3/4W, 1W	±1%,±5%	10mΩ~1Ω	±500~ ±1500
	RS-10	1210	1/3W, 1/2W	±1%,±5%	10mΩ~1Ω	±500~ ±1500
	RS-12	2512	1W~ 2W	±1%,±5%	10mΩ~1Ω	±500~ ±1500

Add to	Series	Size	Power	Tolerance	Resistance	TCR/PPM
	PR02	0402	1/16W	±0.1%~0.5%~±1%	24.9Ω~24.9KΩ	±15/25/50
	PR03	0603	1/16W~ 1/10W	±0.1%~±1%	24.9Ω~332KΩ	±15/25/50
	PR05	0805	1/10W~ 1/8W	±0.1%~0.5%~±1%	10Ω~1MΩ	±15/25/50
	PR06	1206	1/8W~ 1/4W	±0.1%~0.5%~±1%	10Ω~1MΩ	±15/25/50
	PR10	2010	1/4W	±0.1%~0.5%~±1%	10Ω~1.5MΩ	±15/25/50
	PR12	2512	1/2W	±0.1%~0.5%~±1%	10Ω~1.5MΩ	±15/25/50

Add to	Series	Size	Power	Tolerance	Resistance	TCR/PPM
	ARG02	0402	1/16W	±0.5%~±1%	4.7Ω~255KΩ	±25/50
	ARG03	0603	1/10W	±0.5%~±1%	1Ω~1MΩ	±25/50
	ARG05	0805	1/8W	±0.5%~±1%	1Ω~1.5MΩ	±25/50
	ARG06	1206	1/4W	±0.5%~±1%	1Ω~2MΩ	±25/50

Features:

- Advanced thin film technology
- Very tight tolerance down to +-0.01%
-Extremely low TCR down to +-5PPM/ºC
-Wide resistance range 1Ohm~3Mega Ohm
-Miniature size 0201 available

Applcations
- Medical Equipment
-Testing/Measurement Equipment
-Printer Equipment
-Automatic Equipment Controller
-Converters
-Communication Device, Cell phone ,GPS ,PDA

Operating Temperature Range
--55~+155ºC

Ultra Precision Thin Film Resistors

Series	Features
CTR	General size , High precision , Low TCR , Low noise -for reflow /wave soldering both
CTG	high power, Ultra precision , Low TCR , Low noise , AEC-Q200 -for reflow /wave soldering both

Current Sensing Resistors

Series	Features
HTC	High power, Compact, Higher-range resistors - for reflow
HTE	High power, Compact, Higher-range resistors - for reflow/wave soldering both
STC	General size, Simple structure, Low TCR - for reflow
STE	General size, Simple structure, Low TCR - for reflow /wave soldering both
MST	Metal plate , Low TCR , Simple structure - for reflow /wave soldering both
HFCL	Four terminal , High power , Simple structure , Low TCR - for reflow
HFE	Four terminal , High power , Simple structure , Low TCR - for reflow /wave soldering both
SFC	Four terminal , High power , Simple structure , Low TCR - for reflow

Thin Film Resistor

AR	Thin Film Precision Chip Resistor
ARG	Thin Film Chip Resistor
PR	Anti-Corrosive Thin Film Precision Chip Resistor
TFAN	Thin Film Array Chip Resistor
