Product Specifications
| Prod Model: |
PVC-15 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Specifications
1. PWM charge controller
2. Automatic protect
3.12V/24V auto distinguish
4. External temperature transmitter
12V/24V auto. Distinguish, 15A solar charge controller
1. Application: Suitable for 350W/17.5V solar panel.
2. Features and Functions:
1) Charge for 12V lead acid battery
2) High efficient, energy-saving, Safe
3) LEDs instruct charge status, battery capacity and work condition
4) CPM control, offering battery reverse polarity protection, solar module reverse polarity protection, over-current protection, short circuit protection, and open circuit protection.
3. Technical parameters:
1) Input voltage: 17.5 V DC
2) Over charge protection: 14.4 +/- 0.1 V DC
3) Normal output voltage: 12 V DC
4) Max. Output current: 5 A
5) Over discharge cut-off: 11.1 +/- 0.1 V DC
6) Over discharge resume: 13.2 +/- 0.1 V DC
7) Voltage drop between solar panel and battery: 0.4 V DC
8) Voltage drop between battery and load: 0.3 V DC
9) No load current draw: <10 mA
10) Temp. Compensated factor: -3mV/° C per cell
4. Environmental parameters:
1) Operating temperature: -10 ~ +40 ° C
2) Operating humidity: < 90%(RH)
3) Storage temperature: -20 ~ +70 ° C
4) Cooling: Normal conditions
5) Vibration: 5mm / 50 Hz / 600s, Non-operating condition
SOLAR CHARGE CONTROLLER
|
Model
|
PVC-15
|
System Voltage
|
12V/24V AUTO
|
Max.Charge Current
|
15A
|
Float Charge
|
13.7/27.4V
|
Boost Charge
|
14.5/29V
|
Temp.Compensation
|
NO
|
LED Indicator
|
3 LED indicators for different charge status
|
Dimension
|
16.5×10×4.4cm(L×W×H)
|
N.W./unit
|
0.35kg
|
QTY/Ctn
|
50Pcs
|
Packing
|
Gift box
|
Meas./Ctn
|
56.2×35.5×31cm
|
Warranty
|
1 2 Months
|
