Product Specifications
| Prod Model: |
PVC-10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Specifications
LED solar controller
1)Rated Voltage: 12V
2)Maximum Current: 10A
3)DC Load: 12V 10A
4)with 12V/24V auto distinguish
Introduction
Solar charger for lead acid battery
Suitable for small solar power station
Controller function:
High efficient, Energy saving, Safe
Temperature compensated, LCD display
CPM control, offering battery reverse polarity protection, solar module reverse polarity protection, over-current protection, short circuit protection, and open circuit protection.
Specification
Input voltage range: 12~25 VDC
Over charge protection: 13.7 /- 0.1 V
Normal output voltage: 12 VDC
Max. Output current: 20 A
Over discharge cut-off: 10.5 /- 0.1 VDC
Over discharge resume: 12.6 /- 0.1 VDC
Voltage drop: 0.4 VDC (Between input and battery)
Voltage drop: 0.3 VDC (Between battery and load)
No load current draw: < 10 mA
LCD indication: Display AMP/voltage, electric energy instruction
Temp. Compensated factor: From -4 ~ 6 mV/degrees centigrade per unit (optional)
Environment
Operating temperature: -10 ~ 40 degrees centigrade
Operating humidity: < 90%(RH)
Storage temperature: -20 ~ 70 degrees centigrade
Cooling: Normal conditions
Vibration: 5mm / 50 Hz / 600s, Non-operating condition
Mechanical
Plastic casing color: Pantone: 419C, black
Weight: 390 g
Size: 164 X 100 X 48 mm
Safety
Temperature rise: <40 degrees centigrade on plastic casing
MTBF: <10, 000 hours
ESD: 8.0 KV
Model
|
PCV-10
|
Maximum
|
10A
|
System voltage
|
12V or 24VDC
|
Low-voltage cut-off
|
10.5V or 21V
|
Over-charge voltage
|
13.7V or 27.4V
|
NO-load current draw
|
< 100MA
|
Voltage drop from battary and load
|
0.3VDC
|
Operating temperature
|
-10 ºC ~+40 ºC
|
Operating humidity
|
< 90RH
|
Certificate
|
CE ,RoHS
|
Product size
|
13.4*6.8*2.4 CM
|
Carton size
|
45*29.5*45 CM
|
N.W
|
0.15KG
|
G.W
|
0.2KG
|
Packing
|
100pcs/CTN
|
Warranty
|
1 year
|
