Product Specifications

Prod Model:	oem odm
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Min. IC Pitch:	0.30mm(12mil)
Foot Pin:	So, Sop, Soj, Tsop, Tssop, Qfp, BGA and U-BGA
Min. Chip Placement:	01005
Max. PCB Size:	410mm X 600mm(16.2" X 23.6")
Min. PCB Thickness:	0.35mm(13.8mil)
Maximum BGA Size:	74mm X 74mm(2.9" X 2.9")
BGA Ball Pitch:	1mm ~ 3mm(4mil ~ 12mil)
BGA Ball Diameter:	0.4mm ~ 1mm(16mil ~ 40mil)
Qfp Lead Pitch:	0.38mm ~ 2.54mm(15mil ~ 100mil)
Layers:	1 ~ 30 Layers
Base Material:	FR-4
Metal Coating:	Copper
Mode Of Production:	SMT or DIP

Product Description

Tablet pc pcb Double sided PCB board pcb etching

ItemsCapability
1Min. IC Pitch0.30mm(12mil)
2Foot PinSO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA
3Min. Chip Placement 01005
4Max. PCB Size410mm X 600mm(16.2" X 23.6")
5Min. PCB Thickness0.35mm(13.8mil)
6Maximum BGA Size74mm X 74mm(2.9" X 2.9")
7BGA Ball Pitch1mm ~ 3mm(4mil ~ 12mil)
8BGA Ball Diameter0.4mm ~ 1mm(16mil ~ 40mil)
9QFP Lead Pitch0.38mm ~ 2.54mm(15mil ~ 100mil)
10PackageAnti-static Bubble Bag & Carton
PCB Capability

ItemsCapability
1Layers1 ~ 30 layers
2Base MaterialFR4, High Tg FR4, Halogen Free, Isola, Rogers, Aluminium
3Finished Board Thickness0.2mm ~ 7.0mm(8mil-276mil)
4Copper Thickness1/3oz ~ 7oz
5Surface FinishingHASL, Lead Free HASL, Immersion tin, Immersion gold, Gold plating, Immersion silver, OSP, Carbon, etc.
6Reference StandardIPC-A-600H Class 2, Class 3, TS16949
7CertificateUL, ISO9001, RoHS, SGS
8PackageVacuum & Carton
FPC Capability

ItemsCapability
1TypesSingle-sided, Double-sided, Multi-layers (max 6 layers) and
Flex-Rigid PCB
2Surface FinishingHASL(LF), Gold plating, Electroless nickel immersion gold, Immersion Tin, OSP(Entek)
3Base MaterialPolyimide(Kapton), Polyester(PET), FR4
4Soldering Thermal Resistance300° C/10 seconds
5Performance Test100% electrical and electricity performance test

Incoming Quality Control

make inspection according to International Standard and customer requirements.

In-Process Quality Control

Standard manufacturing process and detailed work instructions for each operation station in production line to make sure that operation standard are implemented correctly.

Outgoing Quality Control

We inspect and control strictly the outgoing products quality according to the international standards and customer standards, follow up the quality performance of products after sales and take rapid and effective improvement actions when there are any abnormal quality feedbacks.

Product Return Process

1. Contact us about the defect within 2 weeks upon receiving the products

2. Send detailed digital photos and description of the defect.

3. Wells engineers will review your request and if the products are non-conforming per customer specifications or correlative standard,we will process your request.

4. Upon your approval,we will address the problem and re-run your order based on the original order request.There will be no additional charge.

5. If you quality for a refund,we will refund 100% of your order amount,not including shipping costs.
