Product Description
Features:
1.Micro-Miniature, Innovative design
2.It has good feeling and long life
3.Snap-in type, can be mounted directly on P.C.Board and good for electrostatic discharge
4.It has a lot of choices for button shape and height and it is easily to install
Applications:
Include low power on/off designs, instrumentation, telecommunications, performance audio, computers/servers, networking and more.
1) Computer products
2) Consumer products
3) Communication equipments
4) Instrumentation
Welding Conditions:
1.Hand soldering
Use a soldering iron of 30 watts, controlled at 350ºC approximately 3 seconds while solder applying
2.Wave soldering/Reflow Soldering
The peak temperature of the wave oven should be set to 260ºC max. Condition for soldering Temperature Profile
Material:
1.Keystoke: Nylon/PBT Black
2.Base: Nylon/PBT Black
3.Contact: Copper-silver composite
4.Shell: IRON Tin-plated
5.Terminal: Brass Plating silver
Specification:
Basic Specification Parameter |
|
|
Electrical Characteristics | Rating | DC12V 50mA |
Contact Resistance | ≤100m Ω |
Insulation Resistance | ≥ 100m Ω DC250V |
Withstand Voltage | AC500V 1 Minute |
Electrical Life | 50,000 Cycles above(Load) |
Mechanical/Reliability Characteristics | Operating Force Range | 100/160/250gf |
Mechanical Life | 100,000 Cycles etc (NO Load) |
Operating Temperature Range | -25ºC+ 80ºC |
Ambient Humidity Used | ≤85%RH |
Solder Ability | 245ºC±5ºC 3S |
Withstand Soldering Temperature | 260ºC ±5ºC 3S |
Product Picture & Drawing:
Packaging & Shipping
1) Packaging: Carton
2) Shipping:
Fedex, DHL, UPS, TNT for samples, 3-7 days.
By Air or by Sea for batch goods, 10-30 days.
3) Payment Terms: T/T, L/C, PayPal; 20% deposits; 80% balance before delivery
Why Choose Us?
1) We can provide you with different types of micro switches for your selection.
2) MOQ: 2000pcs,mixed order acceptable, welcome trial order.
3) We can provide free samples for your test.
4) Various operating force, height and colour for one item for your choice.
5) Safety, on-time delivery, excellent quality with competitive price.
6) OEM and ODM professional design.
