High Quality Waterproof Fingerprintrfid Access Control
Product Specifications
| Prod Model: |
SCR100 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| ID Card Capacity: |
30000 |
| Transaction Capacity: |
50000 |
| Communication: |
TCP/IP, RS232/485, USB-Host |
| Access Control Interface For: |
3rd Party Electric Lock, Door Sensor, Exit Button, |
| Optional Functions: |
Mifare, HID |
Product Description
SCR100 is an access control devices produced by ZKSoftware, which is made with elegant design and professional surface treatment. The device have lock control, alarm, exit button, door sensor. The wiegand-in interface is used to connect external reader to construct master and slave system. Also the device can be used to connect with a control panel as a reader by wiegand-out interface. The operation can be done on PC software and upload to the device through TCP/IP, RS232/485 communication. The USB-host is used for data download and upload, including user data and record etc. SCR100 is suitable for house, small office and factory etc.
Features:
Elegant casing design
Easy installation, safe and reliable
Simple and convenient operation method
ID card standard, Mifare card optional
Full door lock control system
Wiegand out to connect with control panel
Wiegand in to construct master and slave system
Audio prompt and LED feedback guide the user to operate
|
ID card Capacity |
30000 |
|
Transaction Capacity |
50000 |
|
Communication |
TCP/IP, RS232/485, USB-Host |
|
Access Control Interface for |
3rd party electric lock, door sensor, exit button, alarm, Door Bell |
|
Wiegand Signal |
Output& Input |
|
Standard Functions |
Anti-passback, Webserver, 9 digital number |
|
Optional Functions |
Mifare, HID |
|
Display |
N/A |
|
Power Supply |
12V DC |
|
Operating Temperature |
0 º C- 45 º C |
|
Operating Humidity |
20%-80% |
|
Dimension(L*W*H)mm |
153x95.5x35.5 |
|
Gross Weight |
0.8KG |
Shenzhen HCC Technology Co., Ltd, established in 2008 year, is a professional manufacturer engaged in the research, development, production, sale and service of Intelligent Commercial Equipment, such as:
Multi-payment product line -- Handheld POS terminal, Retail POS, mPOS etc.
Automatic Fare Collection (AFC) product line -- Bus validator machine and system etc.
E-commerce Logistics and IOT industry product line -- Handheld PDA, Mobile printer, Barcode scanner / printer, RFID device etc.
Our factory had obtained ISO9001 certificates over 15 year, and production department is over 3, 000 SQM. We are also professional in OEM and ODM service, welcome to customize and develop the smart device to meet customers' indeed application.
Most of our products have passed CE/FCC/RoHS international standard, and also approved by Unionpay, EMV, PCI, Visa, MasterCard Industry Professional Certifications, which greatly ensure the highest level safety and quality of our products.
In the past 11 years, we have deepened in printing and payment industry and expanded markets in Southeast and Central Asia, Middle East Asia, South America, Africa and Europe etc. Our products obtain sustained growing market share, and exported to clients over 100 foreign countries and regions.
Our company's slogan is "Professional Solution Provider for Intelligent Commercial Equipment --- Smart and Reliable".
Shenzhen HCC sincerely wish to cooperate with your esteemed company, and provide most suitable products and solution to your customers. We co-create one more Intelligent and glamorous business world.
