Elite Optoelectronics Co., Ltd. >> High Reliable Green Laser Module (GLM) (EL532A01D)

High Reliable Green Laser Module (GLM) (EL532A01D)

Name: High Reliable Green Laser Module (GLM) (EL532A01D)
Brand: china-manufacturer-directory.com
SKU: 708030245
Availability: InStock
Rating: 4.3 (67 reviews)

Supplier:	Elite Optoelectronics Co., Ltd.
Price:	Negotiable/Piece
Min Order:	100/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Prod Model:	EL532A01D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Wavelength:	532nm
Operate Temperature Range:	-10°c~50°c
Life Span:	> 8, 000hrs
Package Type:	Customized
Optical Output Power:	1mw
Delivery Time:	10-20day Depending on The
Power Stability:	>90%
Manufacturing Technology:	Optoelectronic Semiconductor
Material:	Element Semiconductor
Type:	P-type Semiconductor
Package:	Customized

Product Description

1) Wide temp. Operating
2) Low Power Consumption
3) Small Divergence
4) High reliability
5) Mini Size

Green Laser Module ( GLM )
KEY FEATURES
1) Wide temp. Operating
2) Low Power Consumption
3) Small Divergence
4) High reliability
5) Mini Size
6) APC Control

Application
1) Laser Alignment
2) Laser Sight
3) Laser Positioning
4) Surveying Instrument
5) Medical Instrument
6) Military Equipment

Wide temperature operating GLM is our great solution for the narrow operating temperature range of the normal green laser module. Its high brightness, wide operating temperature range are very fit for the use in the wild environments and many tough out door conditions, such as in hot and cold places, deserts or highly humid places.

Specifications	GLM-001	GLM-005	GLM-010	GLM-020
Optical Output Power ( CW)	1mW	5mW	10mW	20mW
Wavelength	532nm
Beam divergence	1.5mrad	0.6mrad	0.4mrad	0.2mrad
Power stability	>90%
Operating temperature	-10 ~ 50°C, 0 ~ 45°C
Housing dimension	¢722mm, ¢ 1022mm, ¢ 1035mm, ¢ 1042mm, ¢ 10 *55mm
	¢ 1222mm, ¢ 1235mm, ¢ 1242mm, ¢ 1255mm

Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.

Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.

Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.

Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
