Product Specifications
| Prod Model: |
EL6D051P1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Delivery Time: |
10-20day Depending on The Qty |
| Lifetime: |
>8000hrs |
| Max. Forward Current: |
30mA |
| Max. Forward Voltage: |
9VDC |
| Dimensions (Mm): |
Customized |
| Output Power: |
5~1000 |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
1, D-series(DOT) laser diode module
2, High quality industrial laser diode
3, driving circuit
4, High reliability
5, Low cost
Industrial laser diode module
1, Long life
2, High quality industrial laser diode
3, APC (Automatic Power Control) driving circuit
4, Low cost
5, High reliability
Application:
1. Industrial Instruments and Equipments
2. Wild Explore Instruments
3. Military Instruments and Equipments
4. Medical Instruments
Elite have many types of DOT laser diode module for different application. The light spot can be ellipse and round shaped with varied beam size, aperture and divergence. The difference depends on the glass lens or plastic lens. Customers can chose different types according to their specific applications.
Note: 1) The DOT laser module has different kinds of lens available for different application. We still have more models like ELxxDxxIG4, ELxxDxxIG5, and ELxxDxxIG10 and so on.
2) Elite Optoelectronics also could offer more kinds of mechanical dimension by customers' requirements
3) DOT laser module still have more wavelength, such as 405nm 480nm 780nm 808nm 850nm 980nm.
Model |
EL65D05P1 |
Wavelength |
650nm |
Output power |
< 3.0mW |
Divergence |
< 0.6mrad |
Beam size(mm) |
< ¢ 1 ( @1m)
|
Lens |
Plastic |
Dimension(mm) |
customized |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
