Price: | US $ 18500Set |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1Set |
Pay Type: | L/C,T/T,Western Union |
Model | QTL-4600-1600mm |
Width of printing meterial | 600-1600mm |
Width of printing | 560-1560mm |
Printing meterial | Non-woven fabric:15-120g, PVC:10~120μm, OPP:10~100μm, BOPP:10~100μm, PE:15~150μm, PET:10~100μm, CPP:10~100μm, Paper:15~400g/m2 |
Printing color | 4 colors |
Length of printing | 200-1100mm |
Plated-glued roller adjusting | Pneumatic Type |
Speed of machine | 10-80m/min |
Printing speed | 10-70m/min |
Overprint precision | Horizontal:+-0.3mm,Vertical:+-0.3mm |
Unwind unit | 1. Auto tension with magnetic powder 2. EPC device |
Rewind unit | 1. Auto tension with magnetic powder 2. Torque motor 3. Surface rolling 4. Two big cylinder 5. Making as your order |
fed and unloated | Air shaft |
Max. unwind&rewind Dia. | 1000mm |
Main motor | 3.5-5.7kw |
Power of heating | 8-12kw |
Power of heating blowers | 1.5-3kw |
Power of cooling blowers | 0.75-1.5kw |
Ink transfer motor | 750w |
The inverter | 3.5-5.7kw |
Metal anilox roller | 30-300 LPI (According to different design and printing) |
Ceramic anilox roller | 50-1000 LPI (According to different design and printing) |
Squeegee | Generalor Closed (as your order) |
Unwinder magnetic | 2.5-20kg |
Rewinder magnetic (or) Torque motor | 5-20kg 20N./m-80N./m |
Tension test | 2~30kg |
Prod Model: | QTL-41200 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Running Way: | Helical Gear |
Anilox Roller: | Metal or Ceramic |
Printing Material: | Paper, Non Woven, Plastic Film |
Printing Colors: | Upon to You |
Type: | Ink Jet |
Plate: | Relief Printing |
Embossing Structure: | Rotary Letterpress |
Color & Page: | Double Faced Multi Colors |
Printing Interface: | No |
Printing Speed: | 70m/ Min |
System Supported: | Manual |
