Product Specifications
| Prod Model: |
ZARE |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| More Spare Parts: |
Yes |
| Place Of Origin: |
Zhejiang,China |
| Condition: |
New |
| After-Sales Service Provided: |
Engineers Available to Service |
| Weight: |
2500kg |
Product Description
Rice Bag Rotogravure Printing Machine (ZRAY)
Application:
This machine is suitable for multi-color once-through continuous printing for such roll film materials with excellent printing performance as BOPP. PET. PVC. PE. Aluminum foil and paper. etc.
Profile:
Gravure printing machine is suitable for many kinds of plastic film. Paper etc roll material printing. Three-motor tension control in closed loop. Computer register. Shaftless. Pneumatic blade. Converter adjust speed. Steady tension. Actually register. High capacity. Reasonable design. Easy to operate and realiable quanlity.
Note: The instead options according to clients? ? Demand: Five motor. Seven motor tension sychronous control system. Can add obverse and inverse double side computer register structure and so on.
Main characteristic
1. Double air-shaft in rewinding. High speed auto receiving material without stop
2. Double air-shaft in unwinding. Semi-automatic cutting and receiving
3. Air cooling device
4. Options: Water cooling device
5. Float roll type double cylinder embossing
6. Shaftless type load plate
7. Double layers cycle hot oven to dry
8. Centralize exhause air device
9. Computer register system(brand according to clients)
10. Inspection unit(brand according to clients)
11. Extra options: Obverse and inverse double printing device
12. Film tension adpots three motor sychronous system(main motor. Unwinding traction. Rewinding traction)
13. Operate man-machine in text
Application: This machine is suitable for multi-color once-through continuous printing for such roll film materials with excellent printing performance as BOPP. PET. PVC. PE. Aluminum foil and paper. etc.
| Type | ZRAY-8800C | ZRAY-81000C | AZJ-81200C |
| Effective Printing Width | 800mm | 1000mm | 1200mm |
| Max. Width of Web | 850mm | 1050mm | 1250mm |
| Max. Printing Speed | 120m/min | 120m/min | 120m/min |
| Max. Mechanical Speed | 140 m/min | 140 m/min | 140 m/min |
| Max. Diameter of Unwind/Rewind | 600mm | 600mm | 600mm |
| Inside Diameter of Roll Core | 76mm | 76mm | 76mm |
| Diameter of Printing Cylinder | 140~360mm | 140~360mm | 140~360mm |
| Accuracy of Computer Registration | ± 0.1mm | ± 0.1mm | ± 0.1mm |
| Tension Control Range | 20~50kg/Full Width | 20~50kg/Full Width | 20~50kg/Full Width |
| Heating Power of Oven | 120Kw | 144Kw | 234Kw |
| Total Power | 181Kw | 205Kw | 266Kw |
| Weight of Machine | 31000kg | 34000kg | 37000kg |
| Overall Dimension | L20000× W3800× H3100mm | L20000× W4000× H3100mm | L20000× W4200× H3100mm |
Our products including :
1. Blown film machines: double layer and 3 layers co-extrusion film blowing machine,
double die head film blowing machine, 3 layers co-extrusion film blowing machine, rotary die dead blown film machine, PVC film making machine, ziplock bag film blowing machine;
2. Bag making machines: bottom sealing bag making machine, side sealing bag making machine, courier bag making machine, double lane bag making machine, ziplock bag making machine, bags en roll making machine, etc;
3. Printing machines: rotogravure printing machine, flexographic printing machine, 1-8 colors for your choice.
4. Other machines: film folding machine, crushing & granulating machine, patch handle sealing machine, glue spraying machine, etc.
5. Machinery accessories: material mixing machine, guesset bag making machine, holes punching die, corona treater etc.
The main packaging products we produce:
1. PE bag, PP bag, OPP bag, PP bag;
2. Carrier bags,T-shirt bag, handle bag, shopping bag, bottom-sealing bag;
3. Courier bag, zip lock bag, self-adhesive bag, side-sealing bag.
4. Styles available: stand up, gusset, zipped, heat-sealed, heat-cut, cold-cut, blown, sealed-in the-middle,three-side-sealed, with handle or hanger hole
