Product Specifications
| Prod Model: |
GS63-05D04 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lifetime: |
>8, 000hrs |
| Delivery Time: |
10-20day Depending on The |
| Max. Forward Voltage: |
3VDC |
| Laser Sight: |
Infrared |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
1, Low power consumption
2, Far-field beam size
3, Small divergence
4, Mini Size
5, High Reliability
Infrared Laser Module GS63-05D04
Infrared laser module was assembled with high quality laser diode, optical glass lenses and Auto Power Control ( APC) electrical circuit. Its high power stability, low power consumption and small far-field beam size make it very fit for the long distance applications.
Key Features
1) high brightness
2) low consumption
3) small divergence
4) high stability
5) high reliability
6) mini size
Application
1) laser alignment
2) laser sight
3) laser positioning
4) surveying instrument
5) medical instrument
6) military equipment
Model |
GS63-05D04 |
Wavelength |
635nm |
Aperture |
4.5mm |
Output Power |
<2.6mW |
Divergence |
<0.1mrad |
Dot Size |
16mm (@20M) |
Lens |
Glass |
Dimension |
8*22mm 10*22mm (APC) |
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
