High Voltage Polymer Composite Pin Insulator (FPA-10/2T16)

Name: High Voltage Polymer Composite Pin Insulator (FPA-10/2T16)
Brand: china-manufacturer-directory.com
SKU: 618783692
Availability: InStock
Rating: 4.3 (122 reviews)

Supplier:	Minyang Group Co., Ltd.
Price:	US $ 18/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	FPA-10/2T16
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage:	10kv
Bending Load:	2kn
Diameter:	146mm
Creepage Distance:	210mm
Model:	Can Be Made to Order
Application:	Insulators
Type:	Solid
Chemistry:	Hybrid Insulation
Material:	Rubber
Thermal Rating:	250 250
Maximum Voltage:	10KV~20KV
Color:	Red
Brand:	Powlik

Product Description

High Voltage Polymer Composite Pin Insulator (FPA-10/2T16)

1.Technical Data

A. Model: FPA-10/2T16
B. Rated Voltage: 10KV
C. Highest Voltage: 12KV
D. Bending Load: 2KN
E. Structure Height: 161mm
F. Max. Dia.: 146mm
G. Min. Arcing Distance: 105mm
H. Min. Creepage Distance: 210mm
I. Dia. Of end thread: 16mm (M16)
J. Power Frequency withstand voltage wet: 28KV
K. Full wave lighting impulse withstand voltage: 75KV

Main Technical Parameters
Type	11KV 10KN
Rated Voltage(KV)	11
Rated mechanical strentch load(KN)	10
Creepage distance(mm)	300
Structure height(mm)	210
Insulating distance(mm)	142
Lightning impulse withstand voltage(KV)	95
1 min wet power frequency withstand voltage(KV)	38
Standard	IEC61952

Minyang Group Co., Ltd. mainly specilized in manufacturing and supply busbar trunking system, power transformer, insulator, fuse cutout, voltage stabilizer, surge arrester, power supply, Load breaker switch, isolating switch, switchgear sets, substations, cables and wires etc.

MINYANG GROUP located in Liushi, the electric capital of China, is specialized in developing, manufacturing and distributing power supplies & switchgears, along with about 150 components.

MINYANG GROUP established with 5 specilized manufacturing factories, Owning skilled workers, advanced equipment and strict quality control process, MINYANG has passed ISO9001: 2000 and obtained CE, CB, CCC etc. Certificates. Our products are enjoying high popularity in Bangladesh, India, UAE, Iran, Saudi, South Africa and Brazil etc.

MINYANG takes "quality is life of enterprise"as its tenet, rewards customers with quality products and perfect services, and creates brilliant future in Chinese electric equipment industry.
