Product Specifications
| Prod Model: |
HLML |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
TECHNOLOGICAL SPECIFICATION
Measuring Range:
Liquid 4.00m 6.00m 8.00m(A) 10.00m 15.00m 20.00m 30.00m
Solid 3.00m 4.00m 6.00m 10.00m 15.00m
Blanking Distance:
Measuring Range 4m 6m 8m(A) 10m 15m 20m 30m
Blanking distance 0.20m 0.25m 0.30m 0.40m 0.60m 0.80m 1.20m
Accuracy: 0.2% Full Span (In air)
Resolution Ratio Shown:
Measuring Range: 4m 6m 8m: 1mm
Measuring Range: 8.00m(A) 10m 15m 20m 30m: 1cm
Mode of Indication: 4 Digit LCD
Output Current: 4~20mA
Output Load: 0~500Ω
Output Resolution Ratio: 0.03% full span
Relay number: Two\four\six
Relay standard: 5A 250VAC/30VDC
Serial communication: RS485
Temperature Range: -40C~85C
Temperature Compensation: The whole range is automatic
Pressure Range: ± 0.1MP (press definitely)
Power Supply:
AC220V(± 20%)0.1A
DC24V( ± 10%)0.1A
Check cycle: 1S
Cable Diameter: 6~12mm
Single Wire Diameter: 0.5~1.78mm
Cable Fix: PG9/ PG11/ PG13.5
Measure Cycle: 1second
Crust Material: ABS
Outer cover grade: IP67
Sensor Material: PVC
