Dongguan Aoke Computer Cutting-off Equipments Co., Ltd. >> Holidays Greeting Card Sample Cutting Plotter

Holidays Greeting Card Sample Cutting Plotter

Holidays Greeting Card Sample Cutting Plotter
Supplier: Dongguan Aoke Computer Cutting-off Equipments Co., Ltd.
Price: Negotiable/Set
Min Order: 1/Set
Quantity::
Trade Terms: FOB
contact supplier

Product Specifications

Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
1200*900: 900*600
Usage: Valentine's Day

Product Description

Holidays Greeting Card Sample Cutting Plotter Replacing the traditional manual paper-cutting operation, it offer precise and efficient cutting and floding solution for card paper, , maker greeting card sample and small production.


Holidays Greeting Card Sample Cutting Plotter feature:

1)tool: Pen, knife and creasing wheel

2) Support half kiss through whole cutting, creasing/score and pen drawing plotting direct onto material

3)cut≤ 2mm 0.1 inch ivory board paper, PVC, plastic sheet make sample and do small production

4)machine size 900mm*600mm 1200mm*900mm 1500mm*900mm 1500mm*1200mm 1800mm*1200mm
Way of fixing material Vacuum absorbing
Driving material Import steel belt
Cut materials Card paper, sticker, vinyl, PVC, PP, film, electronic material, composite material, etc.
Cutting way Drawing by pen, half cutting, whole cutting
Cutting thickness <2mm
Cutting precision ≤0.1mm
Overlapping precision ≤0.1mm
Resolution ratio 0.025mm
Max speed 1000mm/s
Working time and character Continuous work, operating CNC and cutting at the same time, linear high-speed transmission for data.
Transmitting port International standards, parallel port/RSC232 serial port
Capacity of buffer area Buffer area of large capacity, it can finish high-speed transmission for data at a time.
Instruction set International standards: HP-GL or DM-PL from can be selected, it is compatible with all kinds of CAD software.
Numerical control board LCD, all-English operating menu, contact button
Tool type Special steel blade
Pen type General signing pen, oil pen, ball pen
Main structure Cutting platform, head, driving system, control cabinet, control micro computer, frame, vacuum pump
Voltage AC 220v±10% 50Hz
Fuse standard 5A
Reboard Xboard honeycomb corrugated flute carton box sample making machine

1. Laser registration system allows the user to place materials accurately on to the cutting area and to register print.

2. An Infra red safety system protects the operator.

3. Oscillating knife for cutting 15mm/0.6 inch thickness corrugated boards, coroplast, foam, PP corrugated

4. Extra foam tools for cuting 30mm/1.2 inch EPE foam

5. Extra V cut tools for V cut reboard xboard honeycomb chipboard

6. Drag knife for cutting 3mm/ 0.12 inch thickness solid boards

7. Support half kiss through whole cutting, creasing/score and pen drawing plotting direct onto material

8. Suitable for carton factory, printing plant, paper shelf/display manufacturer, packaging material plant, die cut factory, and so on.

9. Machine size 1300mm*1000mm 1700mm*1300mm 2500mm*1600mm 3000mm*1600 mm 3000mm*1800mm 3000mm*2000mm 3500mm*2000mm

Sales@cutcnccam. COM
