This production line consists of two parts: Honeycomb core machine and honeycomb panel lamination unit. These two parts can be connected into two parts, which can be used to make the paper honeycomb board from raw paper in one stop.
|
No. |
Item |
HCM-2200&HF(B)-1800 |
|
1 |
Thickness of honeycomb paperboard |
8-100mm ( 6mm is the limit if the paper and glue reach certain spec.) |
|
2 |
Width of paper core (before expanding) |
2200mm |
|
3 |
Width of paperboard |
1800mm |
|
4 |
Honeycomb core cutting speed |
0-400 cuts/min. |
|
|
Designning speed of production line |
30m/min. |
|
5 |
Normal Speed of paperboard |
6-12m/min. |
|
6 |
Honeycomb board cutting tolerance |
+-1mm |
|
7 |
Honeycomb Cutting tolerance |
+-0.2mm |
|
8 |
Applicable paper |
90-150gsm corrugated paper as core paper,
140-600gsm face paper |
|
9 |
Layers of core paper |
6 |
|
10 |
Cell size |
Four different cell size |
|
11 |
Layers of face paper |
2 |
|
12 |
Heating drying method |
Steam heating |
|
13 |
Total Engine power |
60KW |
|
14 |
Steam requirements |
0.8MPa, 150 degree Celsius, 1 ton/ hour |
|
15 |
Electric heating |
25kw |
|
16 |
Total Installation power |
90kw |
|
17 |
Man power |
5 |
|
18 |
Layout |
86000X4000X2500mm |
|
19 |
Weight |
48Tons |
|
20 |
Power supply |
Three phases, 415V/50Hz |
|
21 |
Color of painting |
Sliver&Grey |
|
22 |
Electric system |
CE standard |
WUXI SHENXI Honeycomb machinery factory, located in Wuxi(near Shanghai), is the China leading manufacture of honeycomb panel machinery industry We have the smooth relationships and cooperation with the related domestic Research & development institutes, the experts and the manufacturer. Based on the guide of the market requirements and relied on the innovative and high technology project, our factory is focusing on the research, development and expends of the honeycomb production equipment and the application of this technology.
Our productions export to Indonesia\Malaysia\Turkey\Thailand\Chile etc. The local customers have: Guangdong\Xiamen\Wenzhou\Hangzhou\ Shanghai\ Nanking\ Qingdao etc. These customers provide a ministrant opportunity for us, and we provide them with satisfying services. We persist in that the customer is the first, with providing wonderful after-sales services. That's the principle of our company.
