Product Specifications
| Prod Model: |
Z-6000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Accuracy: |
>?à1% |
| Principle: |
Impulse-type |
| Measuring Principle: |
Mechanics |
| Measuring Media: |
Liquid and Gas |
| Size: |
1/2-2.5" |
Product Description
Horizontal flowmeter
Horizontal Pipeline Flowmeter
(mount in any position)
Injection molded, chemical resistant Polysulfone
Easy to read scale.
Direct exposure to sunlight is not recommended
Max working pressure 10bar
Max temperature 60C(100C is optional)
Accuracy: FS+/-6%
O-ring: Viton
Kinds of connection: Female(NPT/BSP), male(NPT)
Z-600 SERIES HORIZONTAL PIPELINE FLOW METER:
The main frame of the flow meter of this type is made of engineering plastics of high strength (PC Polycarbonate or polysulfone), which is breaking-proof and corrosion-proof, and can be installed freely. It is capable of bearing high pressure, easy to read (the reading is red), and equipped with indicating device showing the upper and lower limit of the flow, so as to test whether it is beyond the safe limit, the max. Working pressure is 1.0MPa.
Horizontal flow meter OEM(mount in any position) alarm switch is optional
Max press.: 10bar, max. Temp.: 100C
Medium: Water or air
Feature:
Polysulfone material.
Alarm switch is optional
360 degree can installed by any angle
Accuracy: +/-6%
S. S. Connection: 1/2NPTfemale, 3/4NPTfemale or male, 1"NPTmale(BSP is optional)
It is capable of bearing high pressure, easy to read, equipped with indicating device showing the upper and lower limit of the flowx.
Model |
FLOW RANGE |
Thread
S.S.304 |
Weight
KG |
Temp.
C |
Press.
BAR |
|
WATER |
GAS |
|
GPM |
LPM |
GPM |
LPM |
|
Z-6011 |
0.5-5 |
2-20 |
18-180 |
60-600 |
1/2"NPT
3/4NPTM
3/4NPTF |
0.4 |
PSU≤100
PC≤80 |
≤7 |
|
Z-6012 |
1-7 |
4-26 |
20-200 |
70-700 |
|
Z-6013 |
1-10 |
4-35 |
25-250 |
100-1000 |
|
Z-6014 |
1-16 |
5-60 |
35-350 |
150-1400 |
|
Z-6015 |
3-18 |
10-65 |
52-520 |
200-2000 |
3/4NPTM
1NPTM
3/4NPTF |
0.5 |
|
Z-6016 |
4-28 |
20-100 |
80-800 |
300-3000 |
Model |
FLOWRANGE |
FEMALE |
Temp.
C |
Press.
BAR |
|
WATER |
|
GPM |
LPM |
|
Z-6501 |
3-25 |
12-90 |
NPT1 1/2"
NPT2" |
≤80 |
7 |
|
Z-6502 |
5-50 |
20-200 |
|
Z-6503 |
8-80 |
30-280 |
|
Z-6504 |
10-100 |
40-380 |
