Price: | US $ 28500-32500set |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1set |
Pay Type: | L/C,T/T,Western Union |
FOB Price: | US $ 28,500 - 32,500 / Set |
---|---|
Min.Order Quantity: | 1 Set/Sets |
Supply Ability: | 25 Set/Sets per Month |
Port: | xiamen port |
Payment Terms: | L/C,T/T |
1 | Main motor power | standard configuration: Three-phase asynchronous motor:22kw or Hydraulic motor:22kw (depend on final design) |
2 | Suitable material | Cold-rolled steel strip and heat-treated galvanized steel strip |
3 | Thickness of raw material | 1.0-3.0mm |
4 | processing precision within | 1.00mm |
5 | Hydraulic motor power | 5.5kw(depend on final design) |
6 | Hydraulic pressure | 16Mpa |
7 | De-coiler type | Manual de-coiler |
8 | De-coiler drive | 5hp/leveler-3hp |
9 | Weight capacity of decoiler | 5.0T |
10 | Control system | PLC vector inverter:Voltage:380V, 3 phase 50Hz. Dimensions:700mm(L)x1000mm(H)x300mm(W) |
11 | Material of main shaft | 40Cr hardening and tempering |
12 | Diameter of main shaft: | ø70mm |
13 | Material of roller die | Cr15 bearing steel with quenched treatment |
14 | Material of cutting die | Cr12 bearing steel with quenched treatment |
15 | Material of punching die | Cr12 |
16 | Forming step | 16 stations |
17 | Weight | 8.0T |
18 | Transportation | 40 feet container available |
19 | Terms of shipping | FOB/CIF/CRF etc. |
Name | Quanlity | Description |
De-coiler | 1 set | MAX bearing: 5.0T |
Levelling device | 1 set | Material:GCr15 |
Roll forming part | 1 set | GCr15(GCr12 available) |
Straighting device | 1 set | GCr15/45# steel |
Hydraulic mold cutting | 1 set | Cutting material: Cr12/Cr12MoV/Cr12 (total three blades are equiped with these cutting sets) |
Product discharge rack | 1 set | 6m |
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
---|---|
Color: | According to Customer's Request |
Price: | Reasonable |
Delivery Detail: | 45-60 Working Days After Receipt of Deposit |
Type: | Concrete Iron Molding Machinery |
Method: | Hydraulic Pressure |
Processing: | Brick Production Line |
Product: | Tile |
Brick Raw Material: | Concrete |
Automation: | Automatic |
Tolerance: | 1.0mm |
