Product Specifications
Prod Model: |
1220*2440mm |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Max.Width(Mm): |
1220mm |
Max.Length(Mm): |
3000mm |
Thickness Range(Mm): |
3-20mm |
Material: |
Non-asbestos |
Refractory Temperature: |
Over 2000 ℃ |
Grade: |
Grade A |
Type: |
Magnesium Oxide Board |
Usage: |
Building |
Surface Finishing: |
Glossy |
Thickness: |
10mm |
Appearance: |
Panel |
Edge: |
Square |
Shape: |
Rectangle |
Color: |
White, Grey, Green and Red etc. |
Product Description
Magnesium Oxide Wall Board Introduction:
Fireproof board(MGO board) uses propretary processes with MGO, MgCL2, Perlite, Fiberglass. Chip COM-pounds to deliver amulti-purpose, versatile, non-combustible, and unique board material.
Edge:
Our products' edge can be made up into Square, Taper, Beveled, Groove and Tongue etc.
Magnesium Oxide Wall Board Standard size(mm):
900*2700mm/915*2750mm
1200*2300mm/1220*2440mm
1200*2500mm/1220*2500mm
1200*3000mm/1220*3000mm
1. Our Magnesium boards have passed CE, SGS&ISO9001-2000 testings.
2. Special sizes are available by your request.
Magnesium Oxide Wall Board Data information:
Heading | Unit Used | Inspection value | Standard |
Density | G/cm³ | 0.96-1.12g/cm³ | GB 8624 |
Fire ratings | Grade | A1 | GB/T7019-1997 |
Thermal Resistance | M²K/W | 1.14m²K/w | GB/T13475-92 |
Bending Resistance(Dry) | ≤MPa | 18MPa | GB/T7019-1997 |
Bending Resistance(Fully Absorbed in Water) | ≤MPa | 22MPa | GB/T7019-1997 |
Sound Insulation | DB | ≥44dB | GBJ121-88 |
Absorption Moisture | ≤% | ≤15% | GB/T7019-1997 |
Tensile Strength | ≤MPa | 8-13MPa | GB/T7019-1997 |
Impact Resistance | Kj/m² | Between 2.0-2.5 are qualified, For 4mm, our board could reach 4.5kj/m² So our boards are good. | CNS 13778 |
Thickness | Mm | 3mm-20mm | |
Specification | Mm | 1220*2440; 1200*2700; 1200*3000 | |
Color | | White, grey, green and red | |
Main features:
*Outstanding fireproof performance
*Keep warm, insulate against heat, the sound insulation is of good performance
*Scientific prescription, really green environmental protection panel
*Toughness can do the protection against insects, defending ants
*Construction simple, easy and swift, easy to decorate, easy to cut, bore, shear
*Durable, have long performance life
*100% does not include the asbestos
*Applicable to other modeling to decorate for twice
Application:
Our products can apply to Wall Decoration, Ceiling Design, Furniture Decoration, Exterior Wall Decoration, Room Partition and Roof Decoration etc.
Our process:
Raw Material→Producing→Warming→Cutting→Sanding Machine Cutting→Choosing→Packaging→Loading
